PROGRAMMING OFFSET
First select band A or B by pressing [A/B]. Then, if
necessary, press [F], [A/B] to recall the sub-band.
■ Selecting Offset Direction
Select whether the transmit frequency will be higher
(+) or lower (–) than the receive frequency.
Press [F], [MHz] to switch the offset direction.
• “+” or “–” appears to indicate which offset direction is
selected.
• To program –7.6 MHz offset on the TH-D7E (UHF only),
repeatedly press [F], [MHz] until “ ” appears.
If the offset transmit frequency falls outside the
allowable range, transmitting is inhibited. Use one of
the following methods to bring the transmit frequency
within the band limits:
• Move the receive frequency further inside the band.
• Change the offset direction.
Note: While using an odd-split memory channel or transmitting, you
cannot change the offset direction.
STA CON PACKET96BCONDUP
9 7 5
■ Selecting Offset Frequency
To access a repeater which requires an odd-split
frequency pair, change the offset frequency from the
default which is used by most repeaters. The default
offset frequency on the VHF band is 600 kHz no
matter which market version; the default on the UHF
band is 5 MHz (TH-D7A) or 1.6 MHz (TH-D7E).
1 Press [F], [5] to select “F–5 (OFFSET)”.
2 Press [UP]/ [DWN] to select the appropriate offset
frequency.
• The selectable range is from 0.00 MHz to 29.95 MHz
in steps of 50 kHz.
3 Press [OK] to complete the setting.
TH-D7E Only: If you have selected “ ” for the offset direction, you
cannot change the default (7.6 MHz).
Note: After changing the offset frequency, the new offset frequency
will also be used by Automatic Repeater Offset.
STA CON PACKET96BCONDUP
9 7 5
