Page 34
26
S100 User Guide – Rev. D – June 2005
SyncServer S100
Figure 3-5: COM Port Properties
* To set the Terminal Type, select File>Properties>Settings.
7. Click
OK.
8. In the terminal emulation (e.g., hyperterminal) window, select
File->Properties. The
“
Properties” dialog opens. Click Settings tab. Verify the Telnet Terminal ID is set
at
VT100
.
9. Click
OK.
Note:
When your Hyperterminal is connected and operational, at the bottom of the win-
dow you should see the following :
Setting Up the IP Address
1. Power on the S100 unit. The Linux system boots. Various bootup data scrolls on the
terminal emulator’s (e.g., Hyperterminal) screen. This may last a few minutes. When
prompted,
at the User ID login,
type:
root
At the Password prompt,
type:
symmetricom
Note:
The following anomaly occurs when using Hyperterminal in WIN 95: “boot: e”
appears at the prompt interrupting the boot process. Use your backspace key to delete the
“e”. Then press
terminal emulation program, this anomaly may not occur. For security purposes, the root,
or
superuser
, password should immediately be changed using the passwd utility. To do
this, see
“How to change the root password” on page 115.
Keep your newly created password in a safe and secure place. If you should lose it, there is
NO PASSWORD RECOVERY capability with the S100. This means that you will have to
send the S100 back to Symmetricom for recovery!
2. Additional Linux boot-up data appears. When prompted, enter the Login and Password.
Type each one and press
syncserv1 login:
Password:
