SyncServer S100
Pin Descriptions
Operating & Storage
Environments
Temperature and Humidity
0°C to +45°C/5-95% @ 40°C
Options
Long Antenna Cable (Belden 9913), Lightning Arrester, High-gain GPS Antenna,
GPS In-Line Amplifier, Rack Mount Slides
P1: Ethernet RJ45
Description: 8-pin Phone Jack,
Mfr: AMP, Part # 555153-1
Pin Number
Description
1
TX (+)
2
TX (-)
3
RX (+)
4
N/C
5
N/C
6
RX (-)
7
N/C
8
N/C
P3: Serial A (Data Terminal Port/DTE)
Description: 9-pin “D” Plug, Mfr: AMP, Part #
869436
Pin Number
Description
1
RS-232 Data Carrier Detect (in)
2
RS-232 Receive Data (in)
3
RS-232 Transmit Data (out)
4
RS-232 Data Terminal Ready
(out)
5
Ground
6
RS-232 Data Set Ready (in)
7
RS-232 Request to Send (out)
8
RS-232 Clear to Send (in)
9
RS-232 Ring Indicator (in)
S100 Data Sheet Specifications
Component
Specifics
Description
