S100 User Guide – Rev. D – June 2005 13
2
5
3
Chapter 3
Installation and Configuration
Overview
Installation, setup, and getting started with the S100 are reviewed in this section.
Symmetricom recommends you review
before
beginning your installation so that you are already familiar with the references to the interface
once you begin to use it.
Getting Up and Running
This chapter guides you through the following basic steps:
1. Set up the hardware and make all connections ( Optional: Install GPS antenna, connect
phone line).
2. Using the serial cable, establish the S100’s IP address.
3. Test for network functionality (ping).
4. Using the web-based interface, choose and configure the time source.
Unpacking Your S100
Unpack and inspect each item in the box. If there is any damage, or any items are missing,
please contact Symmetricom Customer Assistance (see
“Appendix D” on page 137 ).
Note : The GPS and bullet antennas and antenna cables described in this manual have been
replaced as described in .
The following items should be included:
For the S100-Dial-up/ACTS For the S100-GPS
S100 S100
A/C Power Cord with US-style wall plug A/C Power Cord with US-style wall plug
