USB 598 modem - User Guide
40
2131141
Radio frequency and electrical
specifications
Off
No service is available.
See the suggestions for
Amber,
blinking
coverage is detected. Ready to connect to the
network (click
Connect).
Amber, not
blinking
send or receive data.
Blue,
blinking
coverage (Rev. 0 or Rev. A) is detected.
Ready to connect to the network (click
Connect).
Blue, not
blinking
network,
and can send or receive data.
Table 6-1: LED operation (continued)
LED
State
Indicates
Table 6-2: Radio frequency and electrical
specifications
Approvals
Compliant with:
-2000 Release 1.0 (
)
IS-707-A Data, IS-856 (CDMA
IS-878, IS-890, CDMA Development Group
(ID: N7NU598)
Industry Canada (ID: 2417C-U598)
Voltage
+5.0 Vdc from USB slot
Current
Maximum: 600 mA (from USB port)
Typical data call current (talk mode):
300 mA (1X)
390 mA (1xEV-DO)
Standby:
55 mA (1xEV-DO/IS2000 hybrid
mode)
Transmitter
power
250 mW (+24 dBm) average
Transmit
1850 to 1909.95
Cellular: 824.04 to 848.97 MHz
Receive
PCS:
1930 to 1989.95 MHz
Cellular: 869.04 to 893.97 MHz
GPS:
1575.42 MHz
Channel
spacing
1.25 MHz
