Sony TRUINSTALL USB 598 User Manual
Page 20
USB 598 modem - User Guide
20
2131141
To connect the USB extension cable and laptop clip:
1.
Remove the protective cap from the USB connector of the
modem.
2.
Slide the modem into the laptop clip.
3.
Connect the USB extension cable to the modem.
4.
Insert the other end of the USB extension cable into the
USB slot of your computer.
When the modem and the cable are properly connected,
the
LED indicator is lit (blue, or blinking amber).
5.
Place the laptop clip, with the modem in it, on top of your
laptop screen, as shown in the photo below.
Modem
Laptop clip
USB extension cable
