28
ENGLISH
ESC/POS Mode Commands (TM-290 emulation)
The following table lists the TM-290 emulation commands that are supported
by this printer.
*1: n /60-inch line spacing and paper feed commands:
Since the minimum paper feed pitch for this printer is 1/144 inch, n /60 inch can
considered an approximate value. However, the actual value is INT ((6 n /5) +
0.5)/72 inch.
Control Codes
Hexadecimal
Codes
Function
09 Horizontal tab
0A Line feed
0C Paper eject in single sheet mode
SP 1B 20 Sets size of space to right of character
! 1B 21 Enables batch print mode
# 1B 23 Sets memory switch
* 1B 2A Selects bit image mode
2 1B 32 Selects 1/6-inch line spacing
3 1B 33 Selects approximate n /60-inch line spacing *1
@ 1B 40 Initializes the printer
D 1B 44 Sets horizontal tab position
M 1B 4D Selects the 7 × 9 font
P 1B 50 Selects the 5 × 9 font
