126
APPENDIX
It is not necessary to remove the document table completely, just move it
enough so you can get at the DIP switches inside.
Note:
If the document table seems to be getting caught on the rollers, it means that
you are not pressing down at point (a) enough. Pressing at point (a) should
separate the rollers to the document table can slide freely.
❏
After the document table is opened sufficiently, use a thin flat-blade
screwdriver or some other similar object to change DIP switch settings.
Note:
See the following section for details on available DIP switch settings.
❏
After making the settings you want, slide the document table back into
place while pressing down at point (a). Make sure that the document table
is correctly seated in place before releasing point (a).
❏
Replace the printer cover.
ON OFF
ON
OFF
1 2 3 4 5 6 7 8
(For Serial Interface)
(For Parallel Interface)
ON
OFF
1 2 3 4 5 6 7 8 9 10
