Star Micronics SP298 Series User Manual
Page 139
136
APPENDIX
34
Compulsion
Status
OUT
Compulsion signal (See page 138.)
35
+5V
2.2 k
Ω
pull-up
36
nSelectIn
IN
Unused (However, this becomes a reset signal when DIP switch 1 is set
to ON and DIP switch 2 is set to OFF. See page 128 for details.)
Pin
No.
Signal Name
IN/OUT
Function
This connector mates with an Amphenol
57-30360 connector
Parallel interface connector (printer side)
