Analog Map
Overview 170AMM11030 analog values are mapped as follows.
Note: The display is standardized, and, in each case, the analog value will appear
left justified.
Note: The module resolution is 14-bit (0 ... 32766 decimal or 0 ... 7FFE hex).
0 ... 32766
Input
Word 2
Output
Word 7
to
to
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 msb value input channel 1 lsb 0
0 msb value output channel 1 lsb 0
Input
Word 3
Output
Word 8
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 msb value input channel 2 lsb 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 msb value output channel 2 lsb 0
