Range Output Operating Range
Register for Inputs
Overview The input register is arranged as follows.
Output Voltage Data is Left Justified Comment
Output Range -10.000 ... +10.000 00382 ... 32382 Nominal output voltage
range
Output Over Range +10.000 ... +10.238 32384 ... 32764 Linear over range
output voltage
Output Out of Range ≥10.238 32766
(7FFE Hex)
Threshold limited to
32766 decimal
Output Under Range -10.238 ... -10.000 00002 ... 00382 Linear under voltage
range
Output Out of Range ≤-10.238 00000 Threshold limited to
00000
Word Function
1 Status word (module status)
2 State of the 16 discrete inputs
3 Analog input word channel 1
4 Analog input word channel 2
5 ... 8 Not used
