Control Panel Parts for Models with Rack Timer Controls (RT Models)
See drawing on following page.
Key Part
Number Qty Description
1-22
1179647
1
Control panel assembly, RT, M-Gold, 120V (assembled, w/o wiring harness)
1-23
1179648
1
Control panel assembly, RT, M-Gold, 208/240V (assembled, w/o wiring harness)
*
1179628
1
Wiring harness, RT, 120V (includes terminal block 1170335)
1179634
1
Wiring harness, RT, 208/240V (includes terminal block 1170335)
1
1179706
1
Digital control panel weld asm
2
1177787
1
Polypanel, rack timer control
3
1177598
1
Valve location label
4
1177541
1
Power rocker switch-DPST- (on-off)
5
1177565
1
Light, (amber) 24V
6
1161449
2
Contactor, two pole, 120V
1161525
2
Contactor, two pole, 240V
7
1146399
4
Screw #10x1/2 Philips truss (blunt)
8 1175742 1 Mount,
motor
contactor
9
1173402
1
Rack timer control
10
1146397
4
Screw 8-32 x 5/8 s/steel pan head
11 1172277 1 Transformer,
120/208/240-24
12 6600430 8 Locknut
8-32
13
1175723
1
RAM Ignition control module 24VAC
14 1177515 1 Clamp,
RAM
module
15 1170335 1 Terminal
block
16 1170336 1 Marker
strip
17
1179702
1
Harness, contactor PC/RT
18
1146362
2
Screw 8-32 x 1-5/8 lg. Phillips truss hd
19
1179629
1
RAM mounting bracket
20
1175046
1
Left control panel hinge
21
1177789
1
Rocker switch-SPST momentary
22
1177564
2
Plug, round (120V models)
1170424
2
Fuse holder (208/240V models)
23
1170425
2
Fuse, 12 amp #LP-CC-12 low peak (208/240V models only)
* 1181996 1 Temperature
probe
* not shown on drawing.
