-48-
W1754 20" Planer With Mobile Base
PA
RT
S
Base Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
301
X1754301
ENCLOSED STAND
333
XPW01M
FLAT WASHER 8MM
302
X1754302
COVER
334
XPN03M
HEX NUT M8-1.25
303
XPFH06M
FLAT HD SCR M6-1 X 20
335
XPN02M
HEX NUT M10-1.5
304
X1754304
MOTOR PLATE
336
XPW04M
FLAT WASHER 10MM
305
XPSS04M
SET SCREW M6-1 X 12
337
X1754337
HEX BOLT M8-1.25 X 100
306
X1754306
PLATE CONNECTING ROD
338
XPW01M
FLAT WASHER 8MM
307
XPSS04M
SET SCREW M6-1 X 12
339
X1754339
SPECIAL BOLT
308
X1754308
PLATE CONNECTING ROD
340
XPR21M
INT RETAINING RING 35MM
309
XPB160M
HEX BOLT M10-1.5 X 70
341
XP6202ZZ
BALL BEARING 6202ZZ
310
XPW04M
FLAT WASHER 10MM
342
X1754342
TROLLEY WHEEL
311
XPN02M
HEX NUT M10-1.5
343
X1754343
SLEEVE
312
X1754312
COLLAR
344
X1754344
TROLLEY UNIVERSAL KIT
313
XPSS03M
SET SCREW M6-1 X 8
345
XPW04M
FLAT WASHER 10MM
314
X1754314
ADJUST BOLT
346
XPLN09
LOCK NUT M12-1.75
315
XPN09M
HEX NUT M12-1.75
347
X1754347
HEX BOLT M10-1.5 X 55
316
XPW06M
FLAT WASHER 12MM
348
X1754348
BRACKET
317
X1754317
MOTOR 5HP 240V 1-PH
349
X1754349
PEDAL
317-1 X1754317-1 MOTOR FAN COVER
350
X1754350
COMPLETE MAG SWITCH
317-2 X1754317-2 MOTOR FAN
350-1 X1754350-1 MAG SWITCH BACK COVER
317-3 X1754317-3 R. CAPACITOR 60MFD/400VAC
350-2 X1754350-2 CONTACTOR
317-4 X1754317-4 S. CAPACITOR 300MFD/300VAC
350-3 X1754350-3 THERMAL OVERLOAD RELAY
317-5 X1754317-5 JUNCTION BOX COVER
350-4 X1754350-4 MAG SWITCH FRONT COVER
317-6 X1754317-6 MOTOR LABEL
351
XPSB118M
BUTTON HD CAP SCR M5-.8 X 20
317-7 X1754317-7 CENTRIFUGAL SWITCH
352
XPW02M
FLAT WASHER 5MM
318
XPK12M
KEY 5 X 5 X 30
353
XPN06M
HEX NUT M5-.8
319
XPW01M
FLAT WASHER 8MM
354
X1754354
FRONT COVER
320
XPN03M
HEX NUT M8-1.25
355
XPSBS05M
BUTTON HD CAP SCR M6-1 X 20
321
XPB118M
HEX BOLT M8-1.25 X 45
356
XPFB18M
FLANGE BOLT M8-1.25 X 20
322
X1754322
STRAIN RELIEF
357
X1754357
SWITCH MOUNTING BRACKET
323
XPN03M
HEX NUT M8-1.25
358
XPFB17M
FLANGE BOLT M6-1 X 16
324
XPW01M
FLAT WASHER 8MM
359
XPFB17M
FLANGE BOLT M6-1 X 16
325
X1754325
SLEEVE
360
X1754360
BALL STRAIN RELIEF
326
X1754326
UNIVERSAL PULLEY
361
X1754361
SWITCH BOX
327
XPB163M
HEX BOLT M8-1.25 X 65
362
X1754362
SWITCH FACE COVER
328
X1754328
RUBBER FOOT
363
X1754363
START BUTTON
329
XPR16M
EXT RETAINING RING 9MM
364
X1754364
INDICATOR LIGHT
330
XPW06M
FLAT WASHER 12MM
365
X1754365
STOP BUTTON
331
X1754331
SHAFT 12MM
366
X1754366
TAP SCREW ST4.2 X 8
332
XPSB05M
CAP SCREW M8-1.25 X 50
