3.2. Installation
31
5. To complete installation, rotate the installation cover along the
groove of the ceiling attachment bracket, and fix it.
3.2.6. Installing the Dome Housing (STH-1000PI)
To install the Dome Housing (STH-1000PI), fix it instead of
installing the cover in the last step “3.2.4. Installing the SNP-1000A
on a Ceiling” on page 27 and “3.2.5. Installing the SNP-1000A Wall
Mount” on page 29.
When the Dome Housing is
installed on the ceiling
When the Dome Housing is
installed on the wall
