Location of Parts and Controls
Front Panel / Top Panel / Bottom Panel
2 Tripod screw holes
1 Lens mount
3 Reference holes
(There are four holes
each on the top and the
bottom of the camera.)
1 Lens mount (C-mount)
Used for mounting the C-mount lens and optical
apparatus.
2 Tripod screw holes
The same type of screw hole is provided on both the top
and bottom of the camera. The screw hole (
1 / 4 in., 20
threads) is used for mounting the camera on a ceiling or
on walls, or when using a tripod.
3 Reference holes
Camera mounting holes are machined to high precision
relative to the lens mount. Optical axis stray can be
minimized by mounting the camera using M3 screws
and the reference holes.
