OPERATION
2160 06/11 Operation Section 4-3
© 2011 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
HYDRAULIC BOOM ROTARY CUTTER
Width of Cut 60”
Cutting Height (Min.) 1-3/4”
Cutting Capacity (Max) 2”
Tractor Requirements 100 HP
Hitch Type CAT II-III Q.H.
Overall Width (Head) 69”
Overall Length (Head) 71-3/8”
Transport Width 113”
Driveline CAT 4
Oil Reservoir Capacity 55 Gallons
Blade Tip Speed (FPM) 20,028 FPM
Blade Rotation Clockwise
Blade Carrier Type Pan
Maximum Reach
Horizontal
21’
Vertical 22’, 6”
Down 11’, 6”
Max. Operating Pressure 3000 PSI
Hydraulic Breakaway Standard
Breakaway Pressure 2750 PSI
Range of Head Movement 190 degrees
Deck Thickness 10 Ga.
Side Skirts 1/4” x 9-1/4”
Safety Deflectors Standard
Replaceable Skid Shoes Standard
Weight (Approximate) 2700 lbs. with Oil
EXTRA EQUIPMENT OPTIONAL EQUIPMENT
Hydraulic Relief Arm Kit 540 or 1000 RPM
(For Non-Quick Hitch Tractor) Electro-Hydraulic Cylinder Control Valve Kit
Hyd. Valve Kit for Direct Connect (Tractors with
4-Spool Hyd. Systems)
Operator Protective Cage (Required for use with
all non-cab tractors)
)
READ, UNDERSTAND, and FOLLOW the following Safety Messages. Serious injury or
death may occur unless care is taken to follow the warnings and instructions stated in the
Safety Messages. Always use good common sense to avoid hazards.
(SG-2)
