Identcode ordering system

Pr

o

Minent

®

Identcode ordering system

Please enter the identcode on the device label into the grey box below.

S 2 B a

S i g m a B a s i c Ty p e ( S 2 B a )

HM

Main drive, diaphragm

Pump type: (figures 1+2 = back pressure [bar], figures 3-5 = feed rate [l/h])

16050 16 bar; 50 l/h
16090 16 bar; 90 l/h
16130 16 bar; 130 l/h

12050* 10 bar; 48 l/h
12090* 10 bar; 86 l/h
12030* 10 bar; 125 l/h

07120 7 bar; 120 l/h
07220 7 bar; 220 l/h
04350 4 bar; 350 l/h * for SST versions, max. 12 bar

Liquid end materials:

PV

PVDF

SS

Stainless steel

Seal material:

T

PTFE seal

Diaphragm:

0

Standard diaphragm, PTFE version

1

Double diaphragm with diaphragm rupture indicator (retro fit possible)

Liquid end version:

0

No spring

1

With 2 valve springs, Hastelloy C, 0.1 bar

4

With pressure relief valve, Viton

®

seal, no valve spring

5

With pressure relief valve, Viton

®

seal, and valve spring

Hydraulic connection:

0

Standard threaded connector (according to technical data)

1

Union nut and PVC insert

2

Union nut and PP insert

3

Union nut and PVDF insert

4

Union nut and stainless steel insert

7

Union nut and PVDF hose nozzle

8

Union nut and stainless steel hose nozzle

Version:

0

With ProMinent

®

logo (standard)

1

Without ProMinent

®

logo

Electrical power supply:

S

3 ph, 230 V/400 V 50/60 Hz, 0.18 kW

M

1 ph, AC, 230 V/50/60 Hz, 0.18 kW

N

1 ph, AC 115 V 60 Hz, 0.18 kW

L

3 ph, 230 V/400 V, 50 Hz, (EExe, EExde)

P

3 ph, 230 V/400 V, 60 Hz, (EExe, EExde)

R

3 ph, variable speed motor, 230/400 V, 0.37 kW

V

Variable speed motor with integrated speed control 1 pH,
230 V, 50/60 Hz

Z

1 ph, variable speed control set 1 ph, 230 V, 50/60 Hz

1

No motor, with B14 flange (Gr. 71 (DIN))

2

No motor, C 56 flange (NEMA)

3

No motor, B5 Gr. 63 (DIN)

4

No motor, B5, Gr. 70 (DIN)

Motor version:

0

IP 55 (standard)

1

Exe version (II 2G EExe II T3)

2

Exde version (II 2G EExde IIC T4)

A

ATEX type drive

Stroke sensor:

0

No stroke sensor (standard)

1

with stroke sensor (Hall sensor, no connection cable)

2

Pacing relay (reed relay)

3

Stroke sensor (Namur) intrinsically safe

Stroke length adjustment:

0

Manual (standard)

1

With stroke positioning motor, 230 V/50/60 Hz

2

With stroke positioning motor, 115 V/50/60 Hz

3

With stroke control motor,
0...20 mA 230 V/50/60 Hz

4

With stroke control motor
4...20 mA 230 V/50/60 Hz

5

With stroke control motor
0...20 mA 115 V/50/60 Hz

6

With stroke control motor
4...20 mA 115 V/50/60 Hz

S2Ba

___

___

___

___

___

___

___

___

___

___

___

___

Viton

®

is a registered trademark of DuPont Dow Elastomers.
