Technical data
3.1
Technical data Sigma/ 2
3.1.1
Capacity data
Technical data S2Ba at 50 Hz operation
Feed rate at
Max.
Suction
Admissible
Connection
Shipping
maximum
stroke
lift
priming
suction /
weight
back pressure
rate
pressure
discharge
suction side
side
Pump type Sigma/
bar
l/h
ml/stroke
strokes/min.
m Ws
bar
G - DN
kg
12050 PVT
10
50
11.4
73
7
3
1"-15
15
12050 SST
12
48
11.4
73
7
3
1"-15
20
16050 SST
16
48
11.4
73
7
3
1"-15
20
12090 PVT
10
90
11.4
132
7
3
1"-15
15
12090 SST
12
86
11.4
132
7
3
1"-15
20
16090 SST
16
86
11.4
132
7
3
1"-15
20
12130 PVT
10
130
10.9
198
7
3
1"-15
15
12130 SST
12
125
10.9
198
7
3
1"-15
20
16130 SST
16
125
10.9
198
7
3
1"-15
20
07120 PVT
7
120
27.4
73
5
1
20*
16
07120 SST
7
120
27.4
73
5
1
20*
24
07220 PVT
7
220
27.7
132
5
1
20*
16
07220 SST
7
220
27.7
132
5
1
20*
24
04350 PVT
4
350
29.4
198
5
1
20*
16
04350 SST
4
350
29.4
198
5
1
20*
24
All performance data applies to water at 20 °C.
The suction lift applies when the suction line and liquid end are full and correctly installed.
* Sigma types 07120, 07220 and 04350, the valves used in the liquid end are DN 25 (G1
1
/
2
). Since DN 20 is usually adequate for
this tubing (see Technical Data, connection-suction/discharge side) the connector parts to be ordered by Identcode (e.g.
washers) have already been reduced to DN 20, i.e. tubing and accessories can be DN 20.
Technical data
Technical data S2Ba at 60 Hz operation
Feed rate at
Max.
Suction
Admissible
Connection
Shipping
maximum
stroke
lift
priming
suction /
weight
back pressure
rate
pressure
discharge
suction side
side
Pump type Sigma/
bar
psi
I/h/gph
strokes/min.
m Ws
bar
G - DN
kg
12050 PVT
10
145
60/ 15.9
87
7
3
1"-15
15
12050 SST
12
174
57/ 15.2
87
7
3
1"-15
20
16050 SST
16
232
57/ 15.2
87
7
3
1"-15
20
12090 PVT
10
145
108/ 28.5
156
7
3
1"-15
15
12090 SST
12
174
103/ 27
156
7
3
1"-15
20
16090 SST
16
232
103/ 27
156
7
3
1"-15
20
12130 PVT
10
145
156/ 41
232
7
3
1"-15
15
12130 SST
12
174
150/ 39.6
232
7
3
1"-15
20
16130 SST
16
232
150/ 39.6
232
7
3
1"-15
20
07120 PVT
7
100
144/ 38
87
5
1
20*
16
07120 SST
7
100
144/ 38
87
5
1
20*
24
07220 PVT
7
100
264/ 69.7
156
5
1
20*
16
07220 SST
7
100
264/ 69.7
156
5
1
20*
24
04350 PVT
4
58
420/ 111
232
5
1
20*
16
04350 SST
4
58
420/ 111
232
5
1
20*
24
All performance data applies to water at 20 °C.
The suction lift applies when the suction line and liquid end are full and correctly installed.
* Sigma types 07120, 07220 and 04350, the valves used in the liquid end are DN 25 (G1
1
/
2
). Since DN 20 is usually adequate for
this tubing (see Technical Data, connection-suction/discharge side) the connector parts to be ordered by Identcode (e.g.
washers) have already been reduced to DN 20, i.e. tubing and accessories can be DN 20.
