Scag Power Equipment SCR - Manual (Page 70)

66
REPLACEMENT DECALS AND INFORMATION PLATES
1 2
3
4
7
8
5
ROTATING BLADES AND BELTS
WARNING
KEEP HANDS, FEET & CLOTHING CLEAR
KEEP ALL GUARDS IN PLACE
SHUT OFF ENGINE & DISENGAGE BLADE
CLUTCH BEFORE SERVICING
CLEAR AREA OF DEBRIS BEFORE MOWING
USE CAUTION IN DIRECTING DISCHARGE
KEEP BYSTANDERS, CHILDREN & PETS AWAY
READ INSTRUCTION MANUAL BEFORE OPERATING
DO NOT OPERATE WITHOUT DISCHARGE CHUTE, MULCHING
KIT, OR ENTIRE GRASS CATCHER INSTALLED 481040
DANGER
SPINNING BLADE
KEEP CLEAR
CONTACT CAN INJURE
48071
SCR 2K RD1
WARNING
INSTALL BELT COVER BEFORE
OPERATING MACHINE
READ OPERATOR'S MANUAL
481039
9
482167
START / DRIVE PROCEDURE
ENGAGE PARKING BRAKE
DISENGAGE MOWER DECK DRIVE
MOVE SPEED SELECTOR HANDLES
TO NEUTRAL POSITION
START ENGINE
RELEASE PARKING BRAKE
SELECT SPEED WITH
SELECTOR HANDLE
SELECT FORWARD OR REVERSE
DIRECTION WITH HYDRO
CONTROL HANDLES
CAUTION
BEFORE OPERATING
READ OPERATINGS
MANUAL AND SAFETY
INSTRUCTIONS 482168
CAUTION
KEEP BYSTANDERS AWAY
MANUFACTURED UNDER ONE OR MORE
OF THE FOLLOWING PATENTS:
4, 487, 006 4, 991, 382 5, 832, 708
4, 885, 903 4, 998, 948 5, 865, 018
4, 920, 733 5, 118, 617
4, 967, 543 5, 826, 416
PATENTS PENDING
CUTTING
HEIGHT
4-1/2
4
3-1/2
3
2-1/2
2
1-1/2
1
481863
11
482053
SLOW
FAST
SPEED
SELECTOR
NEUTRAL
N
10
CHOKE
FAST
R
482179
SLOW
MORE
LESS
0
1
2
3
4
5
6
7
8
9
10
PULL OUT TO ENGAGE
PUSH IN TO DISENGAGE
MOWER DECK
START
ON
OFF
ON OFF HOPPER
MOTOR
SWITCH
HOPPER FILL LEVEL
482180 12
13
6
OFF
PARKING
BRAKE
482054
ON
P
DANGER
ROTATING BLOWER
BLADES
STOP ENGINE BEFORE
ENTERING CHUTE
CONTACT CAN INJURE
482080
