12
Section 4
WARNING:
SCR 2K POS
Figure 4-6 Proper Operation on a Slope
To steer left while traveling in reverse, allow the left
steering control lever to move forward. The further the
control is allowed to move forward, the sharper the
mower will turn left.
To steer right while traveling in reverse, allow the right
steering control lever to move forward. The further the
control is allowed to move forward, the sharper the
mower will turn right.
To stop the reverse travel, place the speed control lever
in the neutral position and allow the steering control
levers to return to the neutral position. If the mower is
to be parked, engage the parking brake and remove the
ignition key.
4.6 ENGAGING THE DECK DRIVE (CUTTER
BLADES)
1. Set the throttle at about 3/4 speed. Do not attempt to
engage the deck drive at high speed as this shortens
the electric clutch life — use only moderate engine
speed when engaging the deck drive.
2. Engage the deck drive by pulling out on the yellow
switch, located on the instrument panel, (Figure 4-6)
to the engage position.
3. To disengage the deck drive, push the switch in to
the disengage position.
4. Always operate the engine at full throttle to properly
maintain cutting performance. If the engine starts to
lug down, reduce the forward speed and allow the
engine to operate at maximum RPM.
4.7 HILLSIDE OPERATION
Figure 4-5 Cutter Engage Switch
STT99CES
PULL UP TO ENGAGE
PUSH DOWN TO DISENGAGE
-NOTE-
A squealing noise may be heard when
engaging or disengaging the deck drive. It is
caused by the electric clutch plates meshing
as the mower comes up to speed. This is a
normal condition.
To minimize the possibility of overturning, the least
dangerous method of operating on hills and
terraces is to travel vertically up and down the
slope, not horizontally along the slope. Avoid any
unnecessary turns and travel at reduced speed.
1. The mower has been designed for good traction and
stability under normal mowing conditions. However,
caution must be used when traveling on slopes,
especially when the grass is wet. Wet grass reduces
traction and steering control.
2. To inhibit tipping or loss of control, do not start or
stop suddenly, avoid unnecessary turns and travel at
reduced speed.
3. Keep tires properly inflated.
4. Always travel up or down the slope, whenever
possible; NEVER across the slope. (See Figures 4-6
and 4-7.)
