41
Ref. Part.
No. Number Description
1 482078 Cover, Spring
2 04001-52 Bolt, Hex Head 1/2-13 x 2.5"
3 04019-06 Nut, 1/2-13 Serrated Flange
4 481993 Spring, Cutter Deck LIft
5 04021-09 Nut, 3/8-16 Elastic Stop
6 04001-19 Bolt, Hex Head 3/8-16 x 1"
7 422775 Footplate
8 481284 Bumper, Rubber
9 48114-04 Fitting, Grease
10 451196 Frame, Cutter Deck Mounting
11 04066-01 Pin, Quick
12 48100-17 Bushing, 1" ID Oilite
13 482028-01 Plug, 1/4-28
14 45325 Yoke, Caster
15 04021-07 Nut, 1/2-13 Elastic Stop
16 43511 Spacer
17 04001-80 Bolt, Hex Head 1/2-13 x 6.5"
18 481843 Wheel, Caster 11 x 4.0-5 (Includes items #19 through #24)
19 482192 Tire, 11 x 4.0-5
20 481770 Retainer
21 481846 Roller Bearing .625 x 3.25"
22 481844 Rim, 5.0 x 3.25"
23 481846 Roller Bearing .625 x 1.0"
24 48114-05 Fitting, Grease
25 481245 Knob, Cutter Deck Release
26 43543 Rod, Threaded
27 481992 Spring
28 04060-08 Pin, Roll 3/16 x 1.5"
29 451199 Pin, Deck Frame Pivot
30 04003-04 Bolt, Carriage 5/16-18 x 1"
31 04021-10 Nut, 5/16-18 Elastic Stop
32 04019-03 Nut, 5/16-18 Serrated Flange
33 04040-10 Flatwasher, 5/8-.688 x 1.750 x .134
CUTTER DECK SUPPORT COMPONENTS
