Cutter deck – Scag Power Equipment SCR User Manual
Page 43
39
Ref. Part.
No. Number
Description
1
461330
Cutter Deck with Decals
2
46631
Spindle Assembly
3
481516
Gearbox, Cutter Deck Spindle Drive
4
481632
Wheel, Anti-Scalp
5
43515
Pin, Front Deck Height Adjustment
6
482075
Pin, Rear Deck Height Adjustment
7
422478
Bracket, Anti-Scalp Wheel
8
481625-01
Knob w/Stud
9
422807
LH Belt Cover
422808
RH Belt Cover
10
43309
Spacer, Spinlde Bottom
11
481979
Belt, Cutter Deck Drive
12
48926
Hub, Tapered 1.125" bore
13
48141
Hub, Tapered 1.00" bore
14
48924
Pulley, 5.75" OD Tapered Bore
15
481522
Spring, Belt Tension
16
48753
Pulley, 6.35" OD Tapered Bore
17
481997
Blade, Cutter 16.5" LH
18
451126
Skirt, Weldment Bolt On
19
451091
Baffle, Bolt On
20
43512
Spacer
21
422426
Plate, Gearbox Mounting
22
451096
Idler Arm
23
48224
Bearing, Ball
24
04043-04
Flat Washer 3/8"
25
04021-09
Nut, Elastic Stop 3/8-16
26
48269
Pulley, Idler
27
04001-31
Bolt, Hex Head 3/8-16 x 2.5"
28
04001-136
Bolt, Hex Head 3/8-16 x 1.5 GR8
29
04019-04
Nut, Serr. Flng. 3/8-16
30
422713
Pivot, Idler Arm
31
48269
Pulley, Idler 5.0"
32
48100-15
Bushing .376 ID Oilite
33
04021-05
Lock Nut, 3/8-16 Center Lock
34
04003-26
Bolt, Carriage 3/8-16 x 4.0"
35
04017-27
Bolt, Hex Serr. Flng. 3/8-16 x 1.0"
36
43298
Shaft, Spindle
37
481024
Seal, Top
38
481022
Bearing Assenbly
39
48114-04
Grease Fitting
40
48677
Relief Fitting, Grease
41
43294
Housing, Spindle
42
43312
Spacer, Outside
43
43296
Spacer, Inside
CUTTER DECK
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
44
481025
Seal, Bottom
45
43297
Bushing, Spindle Bottom
46
481035
Nut, Special 1 - 1/16-18
47
04040-10
Flat Washer 5/8"
48
482077
Hinge, Rear Chute
49
482076
Tube, Discharge 8" ID
50
482134
Clamp, Duct 8"
51
451117
Chute, Rear Discharge
52
04001-09
Bolt, HH 5/16-18 x 1.0"
53
04030-03
Lockwasher, 5/16"
54
04040-15
Washer, Flat 5/16"
55
461329
Chute, Side Discharge
56
461328
Bracket, Side Discharge Chute
57
481050
Spring, Discharge Chute
58
04001-108
Bolt, HH 5/16-18 x 4.5"
59
04021-10
Nut, Elastic Stop 5/16-18
60
04001-158
Bolt, 5/8-11 x 9.5" LH Thread
61
04020-29
Nut, 5/8-11 LH Thread
62
04001-10
Bolt, HH 5/16-18 x 1.25"
63
04110-03
U-Nut, 3/8-16
64
04063-08
Key, 1/4 x 1/4 x 2.0"
65
04063-01
Key, 1/4 x 1/4 x 1.25"
66
04001-19
Bolt, 3/8-16 x 1.0"
67
04030-04
Lock Washer 3/8" Spring
68
04003-12
Bolt, Carriage 5/16-18 x .75"
69
04001-01
Bolt, HH 1/4-20 x .75"
70
04003-04
Bolt, Carriage 5/16-18 x 1.0"
71
04019-03
Nut, Serr. Flng. 5/16-18
72
04001-62
Bolt, HH 3/8-16 x 3.25"
73
481988
Driveshaft
74
04021-09
Nut, Elastic Stop 3/8-16
75
04001-21
Bolt, Hex Head 3/8-16 x 1-3/4"
76
04063-01
Key, 1/4 x 1/4 x 1-1/4"
77
451092
Baffle
78
04001-135
Bolt, Hex Head 3/8-16 x 1-3/4" Gr.8
79
04060-08
Roll Pin
80
04062-04
Hair Pin Cotter
81
04040-10
Flatwasher, 5/8-.688 x 1.750 x .134
Ref. Part.
No. Number
Description
