Speco Technologies SIPMPBVFH - Manual (Page 63)

2-59
SIPMPDVFH
Image Sensor 1/3" Micron Progressive Scan CCD
Effective Pixels 1280 x 1024
Electric Shutter
1/10 ~ 1/2,000sec (60Hz)
1/10 ~ 1/2,000sec (50Hz)
Lens Varifocal Lens f=3.3~12mm
Min. scene Illumination 0.5 Lux at F1.0 (2400K, 30IRE)
Synchronization Internal
S/N Ratio Better than 44 dB
Flickerless 1/120 sec(60Hz), 1/100 sec(50Hz)
Day/Night Mechanical IR Cut Filter
White Balance
6Mode(AUTO,INDOOR1/2,OUTDOOR1/2,HOLD
CURRENT,MANUAL) Configurable
AGC Automatic (User defended)
BLC YES
Motion Detection Yes (3 Windows)
Power Source
DC12V (300mA)
PoE (IEEE802.3af) with Class 3
Operational Temperature -29℃ ~ +50℃ ( - 20℉ ~122℉ )
Operational Humidity 30% ~90% RH
Dimensions(HxD) 132 ø x 120.85 mm
Weight 1.4kg
