Speco Technologies COLOR CAMERA WDRT6 User Manual
Wide dynamic range traditional color camera, Wdrt6

Wide Dynamic Range
Traditional Color Camera
For more information contact Speco Technologies
200 New Highway, Amityville, NY 11701 • Toll Free: 1-800-645-5516 • Fax: 631-957-9142 or 631-957-3880
www.specotech.com
WDRT6
simply unique.
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Rev. 10/4/10
Pixim’s patented Digital Pixel System (DPS) technology
marks a fundamental breakthrough in imaging
technology. Pixim has created an image capture and
processing system that provides high-quality pictures
with enhanced dynamic range that
significantly improves image quality
in scenes consisting of both bright
and dark areas. The core invention
in DPS is the inclusion of an
analog-to-digital converter (ADC)
within each pixel of the image
sensor. The ADC translates the
light signal into a digital value at the
immediate point of capture, thus minimizing signal degradation and cross-talk
in the array and allowing for greater noise reduction methods.
Camera Specifications
Resolution
540 TV lines horizontal x 460 lines vertical
Lens Mount
C/CS
Image Sensor
1/3” Pixim ORCA CMOS (dramatic Dynamic range sensor)
Total Pixels
742(H) x 552(V)
Minimum Illumination
0.08 Lux (DSS on)
Electronic Shutter
1/60 - 1/100,000 seconds
Color Balance
Multiple selectable factory pre-sets for most common situations. Full manual override for special applications.
Video Output
1.0 Vp-p into 75 ohm composite
TV System
NTSC/PAL selectable
Scanning System
525 lines interlaced / 625 lines interlaced / Progressive Scan
Synchronization
Internal / External / Line Lock
S/N Ratio
More than 52dB
Dynamic Range
120dB (max), 10dB (typical)
AGC Control
0 - 60dB
OSD Menu Control
4-directional switch with a center push TACT switch
Gamma Characteristic
0.45 NTSC - 0.36 PAL
Power Supply
24 Volts AC, 12 Volts DC- dual voltage
Power Consumption
Max. 2.7 W
Operating Temperature
-20˚F to 122˚F
Powered By
(lens not included)
