ASSY PCB MAIN(OPT)
1 AA94-05592B ASSY PCB MAIN(OPT);WS32W7DH,KS3A/H,TH,IN
2 C815 2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,1
2 CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
2 CX801S 2306-000321 C-FILM,MPPF;470NF,5%,275V,TP,-,22.5
2 IC301 HA96-50406B ASSY-H/S;ASSY-H/S;-,AA62-30180B,LA7845
3 1204-000517 IC-VERTICAL DEF.;LA7845,SIP,7P,-,PLASTIC
3 AA62-30180B HEAT SINK-ES;-,A6063 EXTR.,2,WHT,70MM,-,
3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3 0205-000129 GREASE-SILICON;SC102,JAPAN
2 IC401 1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
2 IC801S HA96-50371C ASSY H/S;-,-,AA62-30181H,KA3A1265R,-
3 AA13-00101A IC HYBRID;KA3S1265RD,CN5039,5PIN,-50TO12
3 AA61-10386A BRACKET-IC;-,SECC 100,T1.0,-,-,-,KA2S068
3 AA62-30197D HEAT SINK-ES;DP,-,-,-,AA62-30181H,-,-,-
3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3 HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE
3 0205-000129 GREASE-SILICON;SC102,JAPAN
2 JA701 3722-000195 JACK-SCART;42P,-,SN,BLK,NO
2 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
2 PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
2 PT801S 1404-000002 THERMISTOR-PTC;9ohm,20%,-,-,TR,RECT,-
2 RL801S 3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,
2 HC801 HA96-00274B ASSY-H/S;-,COMPLEX,AA62-00066B,FMLG12S
3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
3 AA62-00066B HEAT SINK;D2,D3,AL ,T1.0,89,70,-,AA62-00
3 D802 0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220
3 D805 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3 D806 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3 D807 0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3 IC805 1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-,
3 0205-000129 GREASE-SILICON;SC102,JAPAN
2 HC401 HA96-00275D ASSY-H/S;-,COMPLEX,AA62-00051B,2SC5446
3 AA62-00067B HEAT SINK-PS;-,DP,-,-,-,-,AA62-00051B,-
3 D414 0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF,
3 Q401 0502-001175 TR-POWER;2SC5446,NPN,200000mW,TO-3PL,BK
3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3 AA60-30001A WASHER-PLATE;M3,ID3.5,15X8.5,T1.0,SBHG
3 AA62-00092A HEAT SINK;STB,A6063 EXTR.,T1.3,28*28,H12
3 Q401 AA02-00007A SUB ETC-MICA;,MICA,22X30X0.1MM
3 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
3 0205-000129 GREASE-SILICON;SC102,JAPAN
2 D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK
2 IC602 HA96-50369B ASSY-H/S;-,-,AA62-30181F,TDA7297,-
3 1201-001064 IC-POWER AMP;7297,ZIP,15P,-,DUAL,32dB,PL
3 AA62-30181F HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,50MM,-
3 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3 0205-000129 GREASE-SILICON;SC102,JAPAN
2 IC902 1103-001171 IC-EEPROM;L51DC,16KBit,DIP,8P,300MIL,10m
2 C105 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2 C103 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2 C101 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2 C416 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2 C909 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2 C228 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2 C230 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2 C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2 C810 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2 C811 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2 C202 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C205 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C920 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C231 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C215 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C630 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C631 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C645 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C652 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C603 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C207 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C708 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C239 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2 C214 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C605 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C620 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C635 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C646 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C829 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C837 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C839 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C916 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C914 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C831 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C825 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C240 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2 C208 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
2 C636 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
2 C905 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2 C607 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2 C608 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2 C211 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2 C212 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C213 2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
2 C218 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C219 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C220 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C901 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C921 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C919 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C924 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP
2 C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
2 C308 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
2 C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
2 C604 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
2 C201 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
2 C841 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
2 C304 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
2 C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
2 C821 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
2 C902 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
2 C307 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
2 C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
2 C401 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
2 C403 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
2 C421 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
2 C402 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
2 C404 2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
2 C408 2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm
2 C414 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
2 C418 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
2 C422 2401-001527 C-AL;47uF,20%,250V,HR,TP,13x25mm,5m
2 C424 2201-000132 C-CERAMIC,DISC;0.1nF,10%,500V,Y5P,TP,6.5
2 C601 2201-000558 C-CERAMIC,DISC;0.47nF,10%,50V,Y5P,TP,5x3
2 C610 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
2 C611 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm
2 C612 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
2 C613 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
2 C209 2401-001914 C-AL;1uF,20%,50V,BP,TP,5x11,5
2 C617 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
2 C917 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
2 C413 2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
2 C623 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C624 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C627 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C629 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C642 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C644 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C638 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C639 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
2 C249 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP
Electrical Parts List
7-20 Samsung Electronics
7-3 WS32V56VS8XXEC
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
!
