Alignment and Adjustments

Samsung Electronics

4-7

4-8-2 Memory Data

4-8-2(A) DEFLECTION (GEOMETRIC ADJUSTMENT VALUE)

No.

OSD

V Amp

V Shift

V Slope

V SC

H EW

H Trapizium

H Parabola

H Symmetry

H Corner

H Shift

Zoom 4:3 Para

4:3~16:9 Para

Wide-4:3 Para

Wide-Zoom Para

Wide-Zoom2 Para

Zoom1 Amp

Zoom2 Amp

TTX Position

D-TTX Posi

RGB Shift

PIP Contrast

PIP Tint

PIP V.Move(VSPDEL)

PIP PAL V.Pos

PIP NTSC V.Pos

PIP H.Pos

PIP BLKLG

Function

Adjusts Vertical picture size. Adjust 4:4 upper and below picture size in
lion head pattern at factory.

Adjusts Vertical picture position

Adjusts Vertical Slope Correction

Adjusts Vertical s-correction

Horizontal east west width. Adjust 5:5 left and right picture size in lion
head pattern at factory.

Adjusts horizontal Trapezium.

Adjusts Horizontal Parabola.

Adjusts Picture upper and below horizontal Symmetry.

Adjusts Picture upper and below Horizontal Corner.After adjust the
Parabola, adjust H corner vertical Line upper and below has nonlinear.

Adjusts Horizontal Position.

Corrects the vertical linearity in Zoom mode of P-SIZE.
The data depends on CRT (see data above)
Corrects the vertical linearity in 16:9 mode of P-SIZE.
The data differs according to CRT (see data above).
Corrects the vertical linearity in wide mode of P-SIZE.
The data differs according to CRT (see data above).
Corrects the vertical linearity in wide mode of P-SIZE.
The data differs according to CRT (see data above).
Corrects the vertical linearity in wide mode of P-SIZE.
The data differs according to CRT (see data above).
Adjusts vertical amplitude in zoom1

Adjusts vertical amplitude in zoom2. Zoom2 mode is a manual zoom
mode

Sets TTX Position.

Double -TTX position.

Adjusts RGB input signal Horizontal position

Adjusts PIP contrast.
Adjusts PIP Tint. It is a function to control color phase of NTSC signal in
PIP
PIP vertical sync pulse delay. When changing data, PIP jitters at two
points.
In this case, the PIP VSPDEL is set to the center between two points.

Adjusts Vertical position of PIP in PAL system.

Adjusts Vertical position of PIP in NTSC system.

Adjusts Horizontal Position of the PIP.

PIP blanking level green(PIP low light white balance).
It is used to control low light white balance in PIP

Remark

Adjust

Fix

Adjust

Fix

Adjust

Fix

Adjust

Fix
