ASSY PCB MAIN(OPT)
1
AA94-11586A ASSY PCB MAIN(OPT);WS28V5DH,KS3A/H,TH,IN
2
C815
2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,1
2
CN501
3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
2
CX801S
2306-000321 C-FILM,MPPF;470NF,5%,275V,TP,-,22.5
2
IC301
HA96-50406B ASSY-H/S;ASSY-H/S;-,AA62-30180B,LA7845
3
1204-000517 IC-VERTICAL DEF.;LA7845,SIP,7P,-,PLASTIC
3
AA62-30180B HEAT SINK-ES;-,A6063 EXTR.,2,WHT,70MM,-,
3
6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3
0205-000129 GREASE-SILICON;SC102,JAPAN
2
IC401
1202-000103 IC-VOLTAGE COMP.;393,DIP,8P,300MIL,DUAL,
2
IC801S
HA96-50371C ASSY H/S;-,-,AA62-30181H,KA3A1265R,-
3
AA13-00101A IC HYBRID;KA3S1265RD,CN5039,5PIN,-50TO12
3
AA61-10386A BRACKET-IC;-,SECC 100,T1.0,-,-,-,KA2S068
3
AA62-30197D HEAT SINK-ES;DP,-,-,-,AA62-30181H,-,-,-
3
6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3
HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE
3
0205-000129 GREASE-SILICON;SC102,JAPAN
2
JA701
3722-000195 JACK-SCART;42P,-,SN,BLK,NO
2
NT802S
1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
2
PC801S
0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
2
PT801S
1404-000002 THERMISTOR-PTC;9ohm,20%,-,-,TR,RECT,-
2
RL801S
3501-001040 RELAY-POWER;12VDC,500mW,10A,1FormA,15mS,
2
HC801
HA96-00274B ASSY-H/S;-,COMPLEX,AA62-00066B,FMLG12S
3
6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
3
AA62-00066B HEAT SINK;D2,D3,AL ,T1.0,89,70,-,AA62-00
3
D802
0402-001230 DIODE-RECTIFIER;FMG-G2CS,1000V,3A,TO-220
3
D805
0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3
D806
0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3
D807
0402-000233 DIODE-RECTIFIER;FML-G12S,200V,5A,-,-
3
IC805
1203-001006 IC-VOLTAGE REGULATOR;78R05,TO-220F,4P,-,
3
0205-000129 GREASE-SILICON;SC102,JAPAN
2
HC401
HA96-00275D ASSY-H/S;-,COMPLEX,AA62-00051B,2SC5446
3
AA62-00067B HEAT SINK-PS;-,DP,-,-,-,-,AA62-00051B,-
3
D414
0402-001296 DIODE-RECTIFIER;FMP-3FU,1.5KV,5A,TO-3PF,
3
Q401
0502-001175 TR-POWER;2SC5446,NPN,200000mW,TO-3PL,BK
3
6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3
AA60-30001A WASHER-PLATE;M3,ID3.5,15X8.5,T1.0,SBHG
3
AA62-00092A HEAT SINK;STB,A6063 EXTR.,T1.3,28*28,H12
3
Q401
AA02-00007A SUB ETC-MICA;,MICA,22X30X0.1MM
3
6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR
3
0205-000129 GREASE-SILICON;SC102,JAPAN
2
D801S
0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK
2
IC602
HA96-50369B ASSY-H/S;-,-,AA62-30181F,TDA7297,-
3
1201-001064 IC-POWER AMP;7297,ZIP,15P,-,DUAL,32dB,PL
3
AA62-30181F HEAT SINK-ES;-,AL6063 EXTR.,2,WHT,50MM,-
3
6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW
3
0205-000129 GREASE-SILICON;SC102,JAPAN
2
IC902
1103-001171 IC-EEPROM;L51DC,16KBit,DIP,8P,300MIL,10m
2
C105
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2
C103
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2
C101
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2
C416
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2
C909
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
2
C228
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2
C230
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2
C809
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2
C810
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2
C811
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
2
C202
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C205
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C920
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C231
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C215
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C630
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C631
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C645
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C652
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C603
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C207
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C708
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C239
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
2
C214
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C605
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C620
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C635
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C646
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C829
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C837
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C839
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C916
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C914
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C831
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C825
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C240
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
2
C208
2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
2
C636
2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
2
C905
2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2
C607
2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2
C608
2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2
C211
2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
2
C212
2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2
C213
2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
Electrical Parts List
7-10
Samsung Electronics
Level Loc. No. Code No.
Description ; Specification
Remark
Level Loc. No. Code No.
Description ; Specification
Remark
ASSY ACCESSORY
1
AA94-05820A ASSY ACCESSORY;50HZ,KS3A,XEC
2
4301-000120
BATTERY-MN;1.5V,-,AA,14.5x50mm,-
2
HA83-00047A LP-TAPEACETATE;T0.1MM,W20MM,L200MM
2
HA69-00276A BAG VINYL;HDPE,T0.025,L400,W240,-,W/O LO
2
HA68-00335A LABEL CAUTION;A/P100(G),S51A,HUN,POL,-,-
REMOCON
1
AA59-00104K REMOCON;-,TM59,DREAM,29,L/GRAY,PAL-TTX
ASSY POWER CORD
1
AA96-01126B ASSY POWER CORD;DP,AA39-10001G,CP2,H/C40
2
AA39-10001G CBF POWER CORD;-,KKP-419C,KLCE-2F,2.286m
2
AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002
