2 J521 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J523 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J524 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J526 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J527 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J528 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J529 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J530 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 R546 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 JF06 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 JF07 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 R504 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 R509 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 J515 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 R539 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING)
2 DF01 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
2 DF04 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
2 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
2 D507 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 D508 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 D509 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 D510 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 D511 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 D512 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 DF02 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 DF03 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
2 DZ503 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
2 Q501 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
2 QF03 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-
2 QF01 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
2 QF02 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
2 RF09 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 RF12 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 RF10 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 RF11 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 R521 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R526 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 RF08 2001-000313 R-CARBON;11KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 RF03 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R529 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R530 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R536 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 RF04 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2 RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 R520 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
2 RF06 2001-000989 R-CARBON;820KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 R517 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
2 RF14 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,TP,2.4X6.4
2 R502 2001-001049 R-CARBON(S);1.3KOHM,5%,1/2W,AA,TP,2.4X6.
2 R507 2001-001049 R-CARBON(S);1.3KOHM,5%,1/2W,AA,TP,2.4X6.
2 R512 2001-001049 R-CARBON(S);1.3KOHM,5%,1/2W,AA,TP,2.4X6.
2 RF15 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
2 RF17 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4
2 RF13 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
2 RF16 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4
2 R503 2001-001194 R-CARBON(S);82KOHM,5%,1/2W,AA,TP,2.4X6.4
2 R508 2001-001194 R-CARBON(S);82KOHM,5%,1/2W,AA,TP,2.4X6.4
2 R513 2001-001194 R-CARBON(S);82KOHM,5%,1/2W,AA,TP,2.4X6.4
2 R505 2002-001017 R-COMPOSITION;1Kohm,10%,1/2W,AA,TP,3.7x9
2 R510 2002-001017 R-COMPOSITION;1Kohm,10%,1/2W,AA,TP,3.7x9
2 R515 2002-001017 R-COMPOSITION;1Kohm,10%,1/2W,AA,TP,3.7x9
2 RF18 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12
2 RF23 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
2 RF24 2003-000746 R-METAL OXIDE(S);56ohm,5%,2W,AF,TP,4x12m
2 RF19 2003-001023 R-METAL OXIDE(S);120ohm,5%,2W,AF,TP,3.9x
2 RF20 2003-001045 R-METAL OXIDE(S);680ohm,5%,2W,AF,TP,3.9x
2 RF21 2003-001045 R-METAL OXIDE(S);680ohm,5%,2W,AF,TP,3.9x
2 RF22 2003-001045 R-METAL OXIDE(S);680ohm,5%,2W,AF,TP,3.9x
2 RF25 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x
2 RF07 2004-001989 R-METAL;620ohm,5%,1/8W,AA,TP,1.8x3.2mm
2 CF01 2201-000180 C-CERAMIC,DISC;10nF,10%,50V,Y5V,TP,7x3,5
2 CF03 2201-000376 C-CERAMIC,DISC;0.22nF,5%,50V,SL,TP,6.3x3
2 CF06 2201-000516 C-CERAMIC,DISC;4.7nF,+100-0%,500V,Y5U,TP
2 C503 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
2 C506 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
2 C509 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
2 CF04 2201-000653 C-CERAMIC,DISC;0.068nF,5%,50V,SL,TP,5x3,
2 CF08 2201-000653 C-CERAMIC,DISC;0.068nF,5%,50V,SL,TP,5x3,
2 CF14 2401-000832 C-AL;220uF,20%,25V,GP,TP,8x11.5,5
2 CF02 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
2 C516 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
2 C518 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C519 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C520 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C521 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C522 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 C523 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
2 CF05 2301-000261 C-FILM,PEF;4.7nF,5%,100V,TP,10.5x12.5x6.
2 C502 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
2 C505 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
2 C508 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
2 CF07 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
2 C514 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
2 C512 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
2 C515 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
2 C526 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
2 C511 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
2 CF10 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
2 CF12 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5
2 L501 2701-000112 INDUCTOR-AXIAL;100uH,10%,3x7mm
2 LF02 2701-000112 INDUCTOR-AXIAL;100uH,10%,3x7mm
2 LF01 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
2 L505 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
2 L506 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500,
2 PCB AA41-00210D PCB-CRT;CS29A6,FR-1,1L,D,1.6T,330x245,KS
2 DZF01 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
2 DZF02 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T
2 R522 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 R527 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
2 R525 2003-001043 R-METAL OXIDE(S);510ohm,5%,1W,AF,TP,2.5x
2 R518 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x
2 L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
2 L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
2 LF04 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
2 LF05 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
2 R519 2002-001009 R-COMPOSITION;2.7Kohm,10%,1/2W,AA,TP,3.7
2 L507 2701-000215 INDUCTOR-AXIAL;8.2uH,10%,2.5x3.4mm
2 SG501 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
2 SG502 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
2 SG503 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
2 SG504 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
2 SG505 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm
2 R501 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R506 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
2 R511 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
2 HA98-00003A ASSY SUB PART;ASSY-SUB,PART;S53A,PCB,CRT
3 0202-001222 SOLDER-WIRE FLUX;RS-107,RS60-1.2AA,D1.2,
3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb
3 0204-000442 SOLVENT;1M-1000,C3H70H,96,-
3 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,-
2 GT507 AA39-20010D LEAD CONNECTOR-ASSY;,1P,YFH800-01,S,400,
2 CN501A AA39-00225A LEAD CONNECTOR-ASSY;,10P,67096-010,S,600
2 CN501A 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI
2 CN502A AA39-20029K LEAD CONNECTOR-ASSY;,7P,67096-007,S,400,
2 CNF01 AA39-20033C LEAD CONNECTOR-ASSY;,3(2)P,67096-003,S,2
2 CF11 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5
2 C513 2201-000723 C-CERAMIC,DISC;4.7nF,20%,3KV,Y5U,TP,16x5
2 R523 2008-000265 R-FUSIBLE(S);1ohm,5%,2W,AA,TP,3.9x10mm
2 C510 2401-001525 C-AL;47uF,20%,250V,GP,BK,16x25mm,7.
2 JA501 3722-001503 JACK-PIN;1P,1PI,NI,RED,SCR-JACK
2 CNF01 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH
2 CN502A 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
ASSY ETC-PCB A/V BOARD
1 AA95-01518A ASSY ETC-PCB A/V BOARD;,29K8,KS3A,50HZ
2 JH701 3722-000143 JACK-PHONE;1P(VER),3.4PI,AG,BLK,NO
2 JA701 3722-001031 JACK-PIN;3P,3.6mm,#18,AU
2 CN704 AA39-00070A LEAD CONNECTOR-ASSY;,4P,YBNH250-04,35184
Electrical Parts List
7-8 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
