Scag Power Equipment SWU - Manual (Page 31)

27
1 49403 Handle Assembly 16" Frame x x
2 421360 Belt Guard x x
3 04017-27 Capscrw, 3/8-16 x 1" Ser. Flange x x
4 04041-07 Flatwasher, 3/8 (.391 x .938 x .105) x x
5 04021-09 Nut, 3/8-16 Elastic Stop x x
6 481834 Spring, Idler x x
7 04001-10 Bolt, 5/16-18 x 1-1/4" Hex Head x x
8 04021-10 Nut, 5/16-18 Elastic Stop x x
9 04017-05 Capscrew, 1/4-20 x 3/4" Hex Head x x
10 44004 Control Rod, Steering x x
11 04062-02 Hair Pin, Small x x
12 481839 Grip, Shift Lever
13 43032 Swivel Joint x x
14 04062-01 Hair Pin, Large .094 Diameter x x
15 45847 Idler Bracket, RH x x
15A 45846 Idler Bracket, LH x x
16 43092 Idler Sleeve x x
17 04001-62 Bolt, 3/8-16 x 3/4" Hex Head x x
18 04004-17 Support Belt Guard x x
19 04019-04 Nut, 3/8-16 Serrated Flange x x
20 04019-03 Nut, 5/16-18 Serrated Flange x x
21 04017-16 Cpscrw, 5/16-18 x .75" Ser. Flng. x
22 43286 Spacer x x
23 48309 Bushing, Fuel Tank x x
24 48292 Rubber Pad, (Upper) x x
25 46089 Steering Lever x x
26 04017-17 Capscrew, 5/16-18 x 1" Ser. Flng. x x
27 48312 Bushing, Operator Presence x x
28 04040-15 Washer, 5/16 (.375 x .875 x .083) x x
29 48951 Spring, Operator Presence x x
30 45573 Operator Presence Lever, x x
LH (Small Frame)
31 45572 Operator Presence Lever, RH x x
32 44005 Brake Rod x x
33 45092 Brake Lever x x
34 45093 Brake Link x x
35 42254 Brake Link Plate x x
36 04024-01 Nut, 3/8 Push-on x x
37 48114-05 Greese Fitting, Straight 1/4-28 x x
38 04050-01 Retaining Ring, 5/8 Ext. "E" x x
39 48210 Brake Band x x
40 04001-45 Bolt, 3/8-16 x 2" Hex Head x x
41 04031-08 1/4" Internal Tooth Lockwasher x x
42 04032-01 Curved Spring Washer x x
43 04001-32 Bolt, Hex Head 3/8-16 x 1.25" x x
Ref. Part
No. No.
Description
15KA 17KA
HANDLE ASSEMBLY
Ref. Part
No. No.
Description
15KA 17KA
44 04020-02 Nut, 1/4-20 Hex x x
45 461242 Neutral Latch, RH x x
45A 461241 Neutral Latch, LH x x
46 48205 Rubber Pad (Lower) x x
47 48202A Belt, Wheel Drive x x
48 48198 Idler Pulley, Wheel Drive x x
49 48199 Pulley, Jackshaft (Inc. 50) x x
50 04012-04 Setscrew, Hex Socket Knurl x x
Cup Pt. 5/16-18 (nylock)
51 43098 Spacer, Jackshaft Pulley x x
52 48223 Flange, Jackshaft Bearing x x
53 48224 Bearing, Jackshaft x x
54 04050-09 Retaining Ring, 5/8 Ext. Basic x x
55 04017-06 Capscrew, 1/4-20 x 1" Ser. Flange x x
56 04001-62 Bolt, 3/8-16 x 3.25" x x
57 48030-09 Clamp x x
58 04001-17 Bolt, 5/16-18 x 2" Hex Head x x
59 482314 Choke Control x x
60 04040-15 Flatwasher, 5/16 (.375 x .875 x .083) x x
61 04021-02 Nut, 1/4-20 Elastic Stop x x
62 43212 Spacer x x
63 04001-32 Bolt, Hex Head 3/8-16 x 1.25" x x
64 422756 Bar x x
65 48058 Fuel Hose,1/4"ID, 20" (KA ) x
66 48059-01 Clamp, Fuel Hose x x
67 421622 Bracket, Choke Mounting x
68 48159 Grip, Handle x x
69 48308 Valve, Fuel Shut Off x x
70 46846 Fuel Tank Assy.(Incl. Bush. & Val.) x x
71 481603 Fuel Tank Cap x x
72 421239 Strap, Fuel Tank x x
73 04010-10 Screw, 1/4-20 x 2" Rnd Hd Slotted x x
74 422279 Shift Lever x x
75 461163 Shift Lever (Incl. Item 12) x x
76 48144 Grip, Steering Lever x x
77 04041-07 Washer, 3/8 (.391x .938 x .105) x x
78 04020-14 Nut, 3/8-24 UNF x x
79 48028-05 Cable Tie x x
80 04001-53 Bolt, 5/16-18 x 2-1/2" x x
81 461304 Lever, Traction Adjustment W/Grip x x
82 481847 Grip, Traction Adjustment Lever x x
* Common hardware should be purchased locally. All bolts are Grade 5 plated, all other fasteners zinc plated.
