17
1 461363 Cutter Deck (Includes Decals)
2 04017-27 Capscrew, 3/8-16 x 1.0"Serrated Flange Hex Hd
3 422478 Bracket, Anti-Scalp Wheel
4 04021-05 Lock Nut, 3/8-16 Center Lock
5 48100-15 Bushing, 376 ID Oilite
6 481632 Wheel, Anti-Scalp (Incl. Item 5)
7 04003-26 Bolt, Carriage 3/8-16 x 4.0"
8 481838 Pin Assy., Deck Adj. (Incl. Items 10 & 11)
9 43512 Spacer, Deck Adjustment Pin
10 481539 Rod End, Male 3/8-24 RH Thread
11 04020-25 Nut, 3/8-24 Jam
12 46631 Spindle Assembly
13 04021-10 Nut, 5/16-18 Elastic Stop
14 04063-08 Key,1/4 x 1/4 x 2.0"
15 04001-10 Bolt, Hex Head 5/16-18 x 1.50"
16 43309 Spacer, Spindle
17 04040-10 Flatwasher, 5/8 W
18 04001-41 Bolt, Hex Head 5/8-11 x 9.50"
19 481707 Cutter Blade, 18"
19A 48185 Cutter Blade, 18" Hi Lift
20 43299 Spindle Shaft
21 481024 Seal, Cutter Spindle Top
22 481022 Tapered Bearing Set (Two Bearings W/Race)
23 48114-04 Grease Fitting
24 48677 Relief Fitting, Cutter Spindle
25 43294 Spindle Housing
26 43312 Spacer, Outside
27 43296 Spacer, Inside
28 481025 Seal, Cutter Spindle Bottom
29 43297 Spindle Bushing
30 481035 Nut, Spindle
31 422762 Belt Cover, LH
32 481625-01 Wing Nut, 3/8-16
36" CUTTER DECK
Ref. Part
No. Number
Description
Ref. Part
No. Number
Description
33 04021-09 Nut, 3/8-16 Elastic Stop
34 04110-03 U-Nut, 3/8-16
35 04001-31 Bolt, Hex Head 3/8-16 x 2.50"
36 43515 Pin, Deck Adj. Rear
37 04060-08 Pin, Sloted Spring 3/16 x 1.50"
38 48038 Guide, Roller
39 04001-12 Bolt, Hex Head 5/16-18 x 1.75" Front
39 04001-11 Bolt, Hex Head 5/16-18 x 1.50" Rear
40 451118 Roller Shaft
41 48926 Tapered Hub
42 48924 Pulley
43 481880 Belt, Cutter Deck
44 04015-14 Capscrew, Socket Head. 1/4-20 x 1.375"
45 04020-09 Hex Nut, 5/8-11
46 482245 Spring, Chute Return
47 04021-10 Hex Nut, 5/16-18 Elastic Stop
48 04021-09 Hex Nut, 3/8-16 Elastic Stop
49 04043-04 Flatwasher, 3/8 (.938 x .391 x .105) Grade 8
50 04019-04 Nut, 3/8-16 Serrated Flange
51 461291 Discharge Chute, Nylon
52 04001-51 Capscrew, Hex Head 3/8-16 x 3.75"
53 04001-136 Capscrew, Hex Head 3/8-16 x 1.50" Grage 8
54 43510 Pivot, Idler - Long
55 04001-62 Capscrew, Hex Head 38/16 x 3.25"
56 422713 Base, Idler Pivot
57 04003-04 Bolt, Carriage 5/16-18 x 1.0"
58 461174 Idler Arm Weldment
59 48224 Ball Bearing
60 04001-154 Bolt, Hex Head 5/16-18 x 4.75"
61 422763 Belt Cover, RH
62 481597 Spring, Deck Idler
63 481962 Pulley, Idler
64 04030-03 Lockwasher, 5/16 (.317 x .586 x .078)
* Common hardware which should be purchased locally. All bolts are Grade 5 plated, all other fasteners zinc plated.
