23
48" & 52" DECK FRAME
Ref. Part
No. No.
Description
1 461171 Belt Cover With Decal - 48"
1 461279 Belt Cover With Decal - 52"
2 481625-01 Knob With Stud
3 04029-03 Knob, Deck Cover Mounting
4 48100-08 Bushing, Caster
5 451098 Frame Weldment, Deck Mounting - 48"
5 451155 Frame Weldment, Deck Mounting - 52"
6 48114-04 Grease Fitting Str. 1/4-28 Self Tap
7 04066-01 Quick Pin,.438 Dia
8 04024-02 Nut, Push-On - 3/8 Thd.
9 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
10 04019-04 Nut, 3/8-16 Serrated Flange Hex Head
11 45325 Yoke, Caster Wheel
12 04001-80 Capscrew, Hex Head 1/2-13 x 6.50"
13 04021-07 Locknut, 1/2-13 Elastic Stop
14 481843 Wheel Assembly, Caster
15 481845 Tire, 11 x 4.00-5
16 481770 Retainer
17 481846 Roller Bearing
18 481844 Rim, 5.0 x 2.75 With Zerk & Valve
19 48114-05 Grease Fitting Str.1/4-28
20 481769 Roler Bearing .625 x 3.25"
21 * Tire Valve, Purchase Locally
22 04062-04 Hair Pin Cotter, .177 x 3.25"
23 04050-16 Retaining Ring 1.50 Ext.
24 43530 Bushing, Deck Adjustment Pin
25 04017-42 Capscrew, Hex Head 7/16-14 x 1.0"
26 04019-05 Nut, 7/16-14 Serrated Flange Hex
27 04110-03 U-Nut, 3/8-16
28 04001-46 Capscrew, Hex Head 3/8-16 x 2.25"
29 43511 Sleeve, Caster Wheel
30 04040-10 Flatwasher, 5/8 - (.688 x 1.75 x .134)
* Common hardware which should be purchased locally. All bolts are Grade 5 plated, all other fasteners zinc plated.
