Mounting the lens – Samsung SNC-B2331-FRA-QG User Manual
Page 5
English
Power Port
Used to plug the power cable.
Network Port
Used to connect to the Network cable.
I/O Port
ALARM
IN 1,2
Used to connect the alarm input signal.
GND
Used for earth-grounding.
ALARM
OUT 1,2
Used to connect the alarm output signal.
MOUNTING THE LENS
Disconnect the power before proceeding.
Mounting the CS lens
Turn the optional CS lens clockwise to insert it.
CS Lens
