User’s Guide
36
RS-232C Table
You can use the remote control feature by using a PC connected with
an RS-232C cable. The keys on the PC keyboard function similar to the
feature in the SCQ-041P. The following table shows relation between
the PC keyboard and the feature buttons of SCQ-041P.
Keyboard Key (ASCII) Function
A AUTO SWITCHER
R ALARM RESET
E ENTER
Q QUAD DISPLAY
L LIST
S SETUP
1 SINGLE DISPLAY 1
2 SINGLE DISPLAY 2
3 SINGLE DISPLAY 3
4 SINGLE DISPLAY 4
5 FREEZE1 ( ǟ CHARACTER)
6 FREEZE2(CHARACTER Ǟ)
7 FREEZE3(SELECT)
8 FREEZE4(MENU)
Terminal components
• Baud rate : 9600 bps
• Data bits : 8
• Stop bit : 1
• Parity : none
