The MSTR Instruction
840 USE 115 00 Version 1.0 37
3.2.10 Reset Option Module MSTR Operation
The Reset Option Module operation (type 10 in the displayed register of the top
node) causes a Quantum web embedded server module to enter a reset cycle to
reset its operational environment.
Control Block
Utilization The registers in the MSTR control block (the top node) contain the Reset Option
Module information as described in the following table:
3.2.11 Read CTE (Config Extension Table) MSTR Operation
The Read CTE operation (type 11 in the displayed register of the top node) reads a
given number of bytes from the Ethernet configuration extension table to the
indicated buffer in PLC memory. The bytes to be read begin at a byte offset from
the beginning of the CTE. The content of the Ethernet CTE table is displayed in the
middle node of the MSTR block.
Register Function Content
Displayed Operation Type 10
First implied Error status Displays a hex value indicating an MSTR error,
when relevant.
Second implied Not applicable
Third implied Not applicable
Fourth implied Low byte Quantum backplane slot address of the web
embedded server module.
Fifth ... Eighth
implied Not applicable
