Maintenance
840 USE 115 00 Version 1.0 57
If the Coll LED is flashing, the module is reporting collisions on the Ethernet
network. While such collisions are normal, the frequency of the flashes is an
indication of the volume of traffic on the network. The flashes may be so frequent
that the LED appears to be shining steadily. Heavy traffic will slow communications.
If response time is important to your application, you should consider segmenting
your network to reduce the frequency of collisions.
6.1.8 Application LED
If the module crashes, it will note the reason in a log. If the module is able to
recover, the Appl LED will light, indicating that an entry has been made in the error
log. To learn how to read and clear the error log, refer to the section below.
6.1.9 Reading and Clearing the Error Log
If the Appl indicator is lit, entries have been made in the error log. The log may hold
up to 1023 entries. If the error log is full, the Fault indicator will remain on and the
module will be unable to recover until the log is cleared.
You may read the error log while the controller is running or stopped, using the ER-
RLOG utility. However, if you plan to clear the error log, you must stop the controller
first. During the program, ERRLOG will ask you whether you want to stop the con-
troller. If you respond yes, it will stop and restart the controller for you.
To read the error log, at the DOS prompt in the appropriate directory, type:
ERRLOG [/d] [/sxx] [/ny]
where is the Modbus Plus address of the Quantum PLC
is the slot number of the Ethernet web embedded server module.
[/d] is optional, to enable debug messages. Default is no debug.
[/sxx] is optional and specifies the software interrupt to use, xx in
hexadecimal. The default is 5c.
[/ny] is optional and specifies the Modbus Plus adapter number to use, y.
CAUTION
PROCESS INTERRUPTION
Do not stop the controller unless it is safe to stop the operations it is controlling. When a
controller is stopped, all operations under its control will also stop.
Failure to observe this precaution can result in injury or equipment damage.
