Introduction
840 USE 115 00 Version 1.0 7
1.2.1 LED Display
Figure 3 LED Display
Ready Fault
Link
Run Coll
Ethernet TCP/IP
Appl Kernel
Active
140
NOE 211 10
LED Color Indication When On
Active Green Module is communicating with backplane.
Ready Green Module has passed internal diagnostic tests.
Run Green Flashes during normal operation.
Link Green Ethernet link to hub is ok.
Kernel Amber
If steady, module is operating in kernel mode. If
flashing, module is waiting for download.
Fault Red
An error has been detected, a download has failed or
a reset is in process.
Coll Red
If steady, cable is not connected.
If flashing, Ethernet collisions are occurring.
Appl Amber Entry exists in crash log.
