Monitor output level settings
Channel Ref. No. Output level and Switches state ( \ \ \ \ \ : Knob position)
L S902
R S1002
+ 4 dBm/600 Z 0 dBm/600 Z _ 3 dBm/600 Z _ 20 dBm/600 Z
(Factory setting)
Monitor output headroom settings
Channel Ref. No. Output headroom and Switches state ( \ \ \ \ \ : Knob position)
L S900
R S1000
20 dB 18 dB 16 dB 12 dB
(Factory setting)
Monitor output level switching (fixed or variable)
When the variable level is selected, the level is adjusted with the PHONE level control knob.
Channel Ref. No. Setting and Switch state ( \ \ \ \ \ : Knob position)
L S901 Fixed Variable
R S1001
(Factory setting)
1
2 O
N
1
2 O
N
1-10. Analog Audio-related Switch Settings
1 2
O N
3 4 1 2
O N
3 4 1 2
O N
3 4 1 2
O N
3 4
1 2
O N
3 4 1 2
O N
3 4 1 2
O N
3 4 1 2
O N
3 4
