Pin Assignments of
Connectors
INPUT connector
XLR-3-31 (female) equivalent
Pin No.
Signal Remarks
1
GND
Ground of the audio
signal input
2
HOT
HOT of the audio
signal input
3
COLD
COLD of the audio
signal input
ANALOG OUTPUT connector
XLR-3-32 (male) equivalent
Pin No.
Signal Remarks
1
GND
Ground of the audio
signal output
2
HOT
HOT of the audio
signal output
3
COLD
COLD of the audio
signal output
CAMERA connector
12-pin (female)
Miscellaneous
