Section 3
3.3 TRACTOR (CONT'D)
Seat ............................................................................................ Milsco Seat With Adjustment Lever For Forward and Back
Movement
Travel Speed:
Forward ................................................................................ 0 - 8 MPH Infinitely Variable
Reverse ................................................................................. 0 - 4.3 MPH Infinitely Variable
3.4 CUTTER DECK
No. of Blades ............................................................................. 3
Width of Cut:
Mag-61 ................................................................................. 61 in.
Mag-72 ................................................................................. 72 in.
Blade Size:
Mag-61 ................................................................................. 1/4 thick x 21" long, milled edge, 5150 alloy steel
Mag-72 ................................................................................. 1/4 thick x 24-1/2" long, milled edge, 5150 alloy steel
Blade Spindles ........................................................................... Cast Iron with Easy Removable Taper Hubs
Deck Drive................................................................................. Belt Driven Electric Clutch Connected to Drive Shaft to
Gearbox on Deck
Electric Clutch Type ................................................................. Warner “Mag Stop” Electric Clutch
Blade Brake ............................................................................... Lever Controlled Linkage to Band Type Brake. Brake Hub
Connected to Drive Shaft
Cutting Height ........................................................................... Switch on Instrument Panel Controls Electric Actuator;
Cutting Heights - 1-1/2" to 5-1/2"
Deck Tilt .................................................................................... Switch on Instrument Panel Controls Electric Actuator
Cutter Deck Belts:
Blade and Gearbox Drive (Mag-61) .................................... Scag Part Number - 48204
Blade and Gearbox Drive (Mag-72) .................................... Scag Part Number - 48089
Blade Drive (Mag-61) .......................................................... Scag Part Number - 48265
Blade Drive (Mag-72) .......................................................... Scag Part Number - 481295
Gearbox Type............................................................................. Sealed Housing, Bevel Gear and Pinion Type
Drive Shaft ................................................................................ Quick-Disconnect Shaft With Two High Speed U-Joints
3.5 HYDRAULIC SYSTEM
Hydraulic Pump ......................................................................... Sunstrand Series 15
Hydraulic Cooler ....................................................................... Part of Radiator
Hydraulic Oil Filter ................................................................... 10 Micron Spin-on Element Type
Hydraulic Reservoir ................................................................... High Density Polyethylene; 13 Quart Capacity
3.6 WEIGHTS AND DIMENSIONS
Length:
Mag-61 ................................................................................. 120.0"
Mag-72 ................................................................................. 120.0"
Tracking Width:
Mag-61 ................................................................................. 54.0"
Mag-72 ................................................................................. 54.0"
Overall Width:
Mag-61 ................................................................................. 73.0"
Mag-72 ................................................................................. 84.0"
Overall Width (with Discharge Chute Up):
Mag-61 ................................................................................. 62.0"
Mag-72 ................................................................................. 73.0"
Overall Height ........................................................................... 51.0"
Operating Weight:
Mag-61 ................................................................................. 1,750 lb.
Mag-72 ................................................................................. 1,800 lb.
