Scag Power Equipment MAG - Manual (Page 30)

43
Ref. Part Mag Mag
No. Number Description 61 72
1 45733 Cover, Belt X X
2 04029-03 Wingnut, Plastic, 3/8-16 X X
3 04001-52 Bolt, Hex Head, 1/2-13 x 2-1/2 X X
4 481195 Actuator, Deck Lift X X
5 04019-06 Serr. Fl. Hex Nut, 1/2-13 X X
6 04050-05 Retaining Ring, 1.125 Ext X X
7 43356 Pin, Deck support Mounting X X
8 04050-08 Retaining Ring, 1.00 Ext "E" X X
9 45728 Lift Bellcrank, LH Rear X X
10 421878 Link, Deck Support X X
11 04001-117 Bolt, Hex Head, 7/16-14 x 1-3/4 X X
12 04019-05 Serr. Fl. Hex Nut, 7/16-14 X X
13 04063-19 Key, 1/4 x 1/4 x 3/4 X X
14 481215 Spring, Deck Lift X X
15 421838 Anchor, Deck Spring X X
16 04001-119 Bolt, Hex Head, 5/8-11 x 5-1/2 X X
17 04017-16 Serr. Fl. Hex Head CPSCR,
5/16-18 x 3/4
X X
18 422027 Retainer, Spring X X
19 04020-21 Hex Nut, 3/4-16 X X
20 46865 Push Rod Assy (Includes 19, 21, 23,
53)
X X
21 48100-06 Bushing, Olite - 3/4 ID X X
22 04019-03 Serr. Fl. Hex Nut, 5/16-18 X X
23 48114-04 Grease Fitting X X
24 45727 Lift Bellcrank, Front X X
25 45722 Tube, LH Caster (Shown) X
45724 Tube, LH Caster (Shown) X
45723 Tube, RH Caster (Not Shown) X
45725 Tube, RH Caster (Not Shown) X
26 48100-08 Bushing, Olite - 1.00 ID X X
27 43041 Spacer X X
28 48537 Wheel Assembly, Caster (includes
29, 30, 31, 32)
X X
29 48006-07 Retainer X X
30 48006-06 Bearing, Roller X X
31 48537-03 Rim X X
32 48537-02 Tire X X
33 04012-04 Setscrew, Hex Socket, 5/16-18 x .75 X X
34 43022 Sleeve, Caster Wheel X X
35 04001-80 Bolt, Hex Head, 1/2-13 x 6-1/2 X X
36 04021-07 Hex Locknut, Elastic Stop, 1/2-13 X X
37 46869 Frame, Deck Support (Includes 23,
38,39, 74)
X X
Ref. Part Mag Mag
No. Number Description 61 72
38 48100-02 Bushing, Olite - 1-1/8 ID X X
39 48100-08 Bushing, Olite - 1.00 ID X X
40 04021-13 Hex Locknut, Elastic Stop, 5/8-11 X X
41 04042-05 Flatwasher, 1" (1.062 x 1.75 x .10) X X
04041-14 Flatwasher, 1" (1.062 x 1.50 x .048) X X
42 43353 Spacer X X
43 04001-45 Bolt, Hex Head, 3/8-16 x 2 X X
44 04021-09 Hex Locknut, Elastic Stop, 3/8-16 X X
45 04020-09 Hex Nut, 5/8-11 X X
46 43270 Swivel Joint, RH X X
47 04040-09 Flatwasher, 5/8 (.656 x 1.312 x .095) X X
48 04050-01 Retaining Ring, 5/8 Ext "E" X X
49 45731 Lever, Deck Lift X X
50 43271 Swivel Joint, LH X X
51 04064-11 Pin, Clevis, 1/2 x 2.25 X X
52 04044-01 Flatwasher, Nylon, 1" (.54 x 1.125
x 25)
X X
53 481217 Rod End, Male, 3/4-16 RH X X
54 04001-120 Bolt, Hex Head, 3/4-16 x 3 X X
55 04021-14 Hex Locknut, Elastic Stop, 3/4-16 X X
56 43352 Spacer X X
57 04020-04 Hex Nut, 3/8-16 X X
58 43357 Swivel Joint, LH X X
59 44113 Rod, Height Indicator X X
60 04004-15 Stud, Mower Lift X X
61 04063-01 Key, 1/4 x 1/4 x 1-1/4 X X
62 45729 Lift, Bellcrank, RH Rear X X
63 04062-01 Cotter Pin, Hair - 0.94 x 1.62 X X
64 481216 Actuator, Cutting Height X X
65 421834 Link, Deck Travel Limit X X
66 04001-118 Bolt, Hex Head, 1/2-13 x 4-3/4 X X
67 04040-07 Flatwasher, 1/2 (.531 x 1.06 x .095) X X
68 45730 Lever, Bellcrank Actuation X X
69 04001-72 Bolt, Hex Head, 1/2-13 x 2 X X
70 04020-07 Hex Nut, 1/2-13 X X
71 45325 Yoke, Caster Wheel X X
72 04066-01 Quick Pin X X
73 45332 Shaft, Push Rod X X
74 481331 Decal, Cutting Height X X
75 481379 Cover, Spring X X
MAG-61, MAG-72 CUTTER DECK SUPPORT
-NOTE-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
