B Operating Instructions
Looking at the controls
The numbers are keyed to the illustrations in
the Japanese text (pages 11 to 13).
The recorder
1 Display window
2 T MARK button
3 Battery compartment
4 END SEARCH button
5 VOLUME +*/– buttons
* The VOLUME + button has a tactile dot.
6 Terminals for attaching dry battery case
7 DC IN 3V jack
8 GROUP/CANCEL button
9 OPEN button
q; 5-way contorl key
• For basic operations
Press N* to play/enter.
* The N button has a tactile dot.
Press ./> to rewind/fast
forward.
Press X to pause.
Press CHGx to stop/charge.
• For moving the cursor and entering
selected items (during text entry and
other settings).
qa Jog dial (MENU/ENTER)
Press to enter the menu, turn to select,
and then press to enter.
qs LINE IN (OPT) jack
qd MIC (PLUG IN POWER)* jack
* There is a tactile dot beside the MIC
(PLUG IN POWER) jack.
qf REC (record) switch
qg HOLD switch (at the rear)
qh i/LINE OUT jack
The display window of the
recorder
1 Character information display
Displays the track, group, or disc
name*, date, error messages, track
numbers, etc.
* Names appear only with MDs that have
been labeled.
2 Group indication
3 Disc indication
Shows that the disc is rotating for
recording, playing or editing an MD.
English
4 REC indication
Lights up while recording. Flashes
when standing by for recording.
5 SYNC (synchro-recording) indication
Lights up while synchro-recording.
6 Play mode indication
Shows the play mode of the MD.
7 Level meter
Shows the level of the MD being
played.
8 LP2 (LP2 stereo), LP4 (LP4stereo),
MONO (monaural) indication
9 Sound indication
Lights up when Digital Sound Preset is
on.
q; Battery level indication
Shows approximate battery condition.
While charging the rechargeable
battery, this indication shows the
charging condition.
qa Melody timer indication
The headphones/earphones with
a remote control
1 DISPLAY button
2 PLAY MODE button
3 RPT/ENT(repeat/enter) button
4 SOUND button
5 X (pause) button
6 x (stop/enter) button
7 Clip
8 Control (./N>)
N> : play, AMS, FF
. : REW
Turn or turn and hold to play, fast
forward, rewind, etc.
9 Control (VOL +/–)
Pull and turn to adjust the volume.
q; Display window
qa HOLD switch
The display window of the
remote control
1 Disc indication
2 Track number display
3 Character information display
4 Play mode indication
5 SOUND indication
6 Battery level indication
7 REC indication
8 Group indication
9 Melody timer indication
