D
ESCRIPTION OF
H
ARDWARE
2
• Light weight, compact construction with versatile switch stand
for installation on a desktop or wall.
Front Panel LEDs
The front panel of the switch provides status LEDs for “at-a-glance”
system monitoring. The following table details the functions of the
various indicators.
Port and Switch Status LEDs
LEDs Condition Status
Power Green Switch is receiving power.
Link/Activity Yellow Indicates a valid 10BASE-T connection
between the port and the attached
device.
Flashing
Yellow Indicates that the port is transmitting or
receiving data at 10 Mbps.
Green Indicates a valid 100BASE-TX connection
between the port and the attached
device.
Flashing
Green Indicates that the port is transmitting or
receiving data at 100 Mbps.
