Connections
Antenna Connection
AUDIO IN
(RGB/DVI)
DIGITAL AUDIO
OUT(COAXIAL)
ANTENNA/
CABLE IN
AV IN
AUDIO
L
VIDEO
R
Multi-family Dwellings/ Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Wall Antenna Socket
RF Coaxial Wire (75 ohm)
VHF
UHF
Outdoor Antenna
Turn clockwise to tighten.
Be careful not to bend the bronze wire when
connecting to an antenna port.
* Separately purchase a RF Coaxial Wire(75 ohm)
- To improve the picture quality in a poor
signal area, please purchase a signal
amplifier and install properly.
- If the antenna is not installed properly,
contact your dealer for assistance.
NOTE
AUDIO IN
(RGB/DVI)
DIGITAL AUDIO
OUT(COAXIAL)
ANTENNA/
CABLE IN
AV IN
AUDIO
L
VIDEO
R
VHF
UHF
Signal
Amplifier
