23
SPECIFICATIONS
Name Blood Bank Refrigerator
Model MBR-304D MBR-304G MBR-304DR MBR-304GR
External dimensions W600 x D680 x H1835 (mm)
Internal dimensions W520 x D490 x H1150 (mm)
Effective capacity 304 L 302 L
Exterior Acrylic finish baked on zinc galvanized steel
Interior Acrylic finish baked on zinc galvanized steel
Door 1 door with glass window
Insulation Rigid polyurethane foamed-in place
Shelf Hard steel wire on polyethylene coating
5 pcs.
-----
Drawer ----- Stainless steel, Handle with card holder
5 pcs.
Access port Left side, Inner diameter 30 mm
Cooling method Forced cool air circulation
Compressor Hermetic type, Output; 175 W
Condenser Fin and tube type
Evaporator Fin and tube type
Refrigerant R-134a
Temperature controller Electronic control system
Temperature display Digital display
Alarm High temperature, Low temperature, Door, Power failure, Sensor
Remote alarm contact Allowable contact capacity: 30 VDC, 2 A
Memory back-up Nonvolatile static memory
Fluorescent lamp White light 15 W x 1 (Glow starter; FG-1P)
Temperature recorder 30-day type 7-day type 30-day type 7-day type
Accessories 1 set of key
Battery 6 VDC, 1100 mAh (Ni-MH)
Weight 125 kg 140 kg
Note The contents of this manual are subject to change without notice.
PERFORMANCE
Monitor bottle temperature +4
o
C 1
o
C
Usable ambient temp. +5 to 35
o
C
Power failure alarm
duration
24 hours (when the battery is full charged)
Power source 110V
60Hz
115V
60Hz
220V
50Hz
220 V
60Hz
230 V
50Hz
240 V
50Hz
220-240V,
50Hz
Rated power consumption 220W 220W 220W 220W 220W 220W 220W
Noise level 41 dB [A] (background noise; 20 dB)
Maximum pressure 1275 kPa
Note The unit with CE mark complies with EC directives 89/336/EEC, 93/68/EEC and 73/23/EEC.
