– 107 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
R1826
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1827
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1828
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1829
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1830
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1831
1-216-063-91 RES,CHIP
3.9K
5%
1/10W
R1832
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1833
1-216-041-00 RES,CHIP
470
5%
1/10W
R1834
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1835
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1836
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1837
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1838
1-216-041-00 RES,CHIP
470
5%
1/10W
R1839
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1840
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1841
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1842
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1843
1-216-041-00 RES,CHIP
470
5%
1/10W
R1844
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1845
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1846
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1847
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1848
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1849
1-216-041-00 RES,CHIP
470
5%
1/10W
RY1601 1-755-028-11 RELAY
RY1602 1-755-028-11 RELAY
TB1601 1-694-303-11 TERMINAL, PUSH
X1701
1-579-125-11 VIBRATOR, CERAMIC (8.0MHz)
*****************************************************************************
* A-1346-679-AE BOARD, COMPLETE
***************************
4-382-854-11 SCREW (M3X10), P, SW (+)
7-682-952-09 SCREW +PSW 3X16
C502
1-126-959-11 ELECT
0.47
µ
F
20% 50V
C505
1-130-471-00 FILM
0.001
µ
F
5%
50V
C506
1-126-933-11 ELECT
100
µ
F
20% 16V
C507
1-126-965-11 ELECT
22
µ
F
20% 50V
C508
1-102-228-00 CERAMIC
470pF
10% 500V
C509
1-106-383-00 MYLAR
0.047
µ
F
10% 200V
C511
1-130-475-00 MYLAR
0.0022
µ
F
5%
50V
C512
1-136-479-11 FILM
0.001
µ
F
5%
50V
E
D
R1753
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1754
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1755
1-216-025-00 RES,CHIP
100
5%
1/10W
R1756
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1757
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1758
1-216-025-00 RES,CHIP
100
5%
1/10W
R1759
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1760
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1762
1-216-065-00 RES,CHIP
4.7K
5%
1/10W
R1763
1-216-666-11 METAL CHIP
4.3K
0.50%1/10W
R1764
1-216-065-00 RES,CHIP
4.7K
5%
1/10W
R1765
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1766
1-216-049-91 RES,CHIP
1K
5%
1/10W
R1767
1-216-113-00 RES,CHIP
470K
5%
1/10W
R1768
1-216-049-91 RES,CHIP
1K
5%
1/10W
R1769
1-216-115-00 RES,CHIP
560K
5%
1/10W
R1770
1-216-049-91 RES,CHIP
1K
5%
1/10W
R1771
1-216-113-00 RES,CHIP
470K
5%
1/10W
R1772
1-216-049-91 RES,CHIP
1K
5%
1/10W
R1773
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1774
1-216-025-00 RES,CHIP
100
5%
1/10W
R1775
1-216-115-00 RES,CHIP
560K
5%
1/10W
R1778
1-216-049-91 RES,CHIP
1K
5%
1/10W
R1786
1-216-025-00 RES,CHIP
100
5%
1/10W
R1787
1-216-025-00 RES,CHIP
100
5%
1/10W
R1788
1-216-025-00 RES,CHIP
100
5%
1/10W
R1789
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1790
1-216-025-00 RES,CHIP
100
5%
1/10W
R1791
1-216-025-00 RES,CHIP
100
5%
1/10W
R1792
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1793
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1794
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1795
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1802
1-215-925-11 METAL OXIDE 22K
5%
3W
F
R1803
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1804
1-216-113-00 RES,CHIP
470K
5%
1/10W
R1805
1-216-113-00 RES,CHIP
470K
5%
1/10W
R1806
1-216-023-00 RES,CHIP
82
5%
1/10W
R1807
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R1808
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R1809
1-216-097-00 RES,CHIP
100K
5%
1/10W
R1810
1-216-023-00 RES,CHIP
82
5%
1/10W
R1811
1-216-025-00 RES,CHIP
100
5%
1/10W
R1812
1-216-025-00 RES,CHIP
100
5%
1/10W
R1813
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1814
1-216-023-00 RES,CHIP
82
5%
1/10W
R1815
1-216-025-00 RES,CHIP
100
5%
1/10W
R1816
1-216-025-00 RES,CHIP
100
5%
1/10W
R1817
1-216-025-00 RES,CHIP
100
5%
1/10W
R1818
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R1819
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R1820
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R1821
1-216-025-00 RES,CHIP
100
5%
1/10W
R1822
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1823
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1824
1-216-089-00 RES,CHIP
47K
5%
1/10W
R1825
1-216-089-00 RES,CHIP
47K
5%
1/10W
