Page 55
– 93 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
C122
1-163-137-00 CERAMIC CHIP 680pF
5%
50V
C123
1-163-113-00 CERAMIC CHIP 68pF
5%
50V
C124
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C125
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C126
1-126-933-11 ELECT
100
µ
F
20% 16V
C127
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C128
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C129
1-163-089-00 CERAMIC CHIP 6pF
0.5pF 50V
C130
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C131
1-104-664-11 ELECT
47
µ
F
20% 16V
C132
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C133
1-126-963-11 ELECT
4.7
µ
F
20% 50V
C134
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C135
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C136
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C137
1-104-664-11 ELECT
47
µ
F
20% 16V
C138
1-126-964-11 ELECT
10
µ
F
20% 50V
C139
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C143
1-104-664-11 ELECT
47
µ
F
20% 16V
C144
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C145
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C146
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C147
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C148
1-126-933-11 ELECT
100
µ
F
20% 16V
C149
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C150
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C151
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C152
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C153
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C154
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C155
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C201
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C202
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C203
1-104-661-91 ELECT
330
µ
F
20% 16V
C204
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C205
1-126-965-11 ELECT
22
µ
F
20% 50V
C206
1-163-275-11 CERAMIC CHIP 1000pF
5%
50V
C207
1-126-964-11 ELECT
10
µ
F
20% 50V
C208
1-126-965-11 ELECT
22
µ
F
20% 50V
C209
1-126-964-11 ELECT
10
µ
F
20% 50V
C210
1-216-295-00 SHORT
0
C211
1-126-965-11 ELECT
22
µ
F
20% 50V
C212
1-164-346-11 CERAMIC CHIP 1
µ
F
16V
AE
NOTE:
• The components identified by
in this manual have
been carefully factory-selected for each set in order to
satisfy regulations regarding X-ray radiation. Should
replacement be required, replace only with the value
originally used.
• Items marked " * " are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
• All variable and adjustable resistors have characteristic
curve B, unless otherwise noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
• CAPACITORS
PF :
µµ
F
• There are some cases the reference number on
one board overlaps on the other board. Therefore,
when ordering parts by the reference number,
please include the board name.
SECTION 8
ELECTRICAL PARTS LIST
* A-1298-318-A AE BOARD, COMPLETE
*****************************
(KP-41S5/41S5B/41S5U)
* A-1298-455-A AE BOARD, COMPLETE (KP-41S5G)
*****************************
* A-1298-456-A AE BOARD, COMPLETE (KP-41S5K)
*****************************
* A-1298-457-A AE BOARD, COMPLETE (KP-41S5R)
*****************************
1-750-797-11 SOCKET, PLCC
C1
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C2
1-104-664-11 ELECT
47
µ
F
20% 16V
C3
1-163-239-11 CERAMIC CHIP 33pF
5%
50V
C4
1-163-239-11 CERAMIC CHIP 33pF
5%
50V
C8
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C10
1-163-243-11 CERAMIC CHIP 47pF
5%
50V
C11
1-163-243-11 CERAMIC CHIP 47pF
5%
50V
C14
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C15
1-163-133-00 CERAMIC CHIP 470pF
5%
50V
C18
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C19
1-163-017-00 CERAMIC CHIP 0.0047
µ
F
10% 50V
C20
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C21
1-164-232-11 CERAMIC CHIP 0.01
µ
F
10% 50V
C22
1-163-251-11 CERAMIC CHIP 100pF
5%
50V
C24
1-163-275-11 CERAMIC CHIP 1000pF
5%
50V
C25
1-104-664-11 ELECT
47
µ
F
20% 16V
C26
1-104-664-11 ELECT
47
µ
F
20% 16V
C43
1-163-121-00 CERAMIC CHIP 150pF
5%
50V
C45
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C90
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C101
1-163-038-00 CERAMIC CHIP 0.1
µ
F
25V
C102
1-126-934-11 ELECT
220
µ
F
20% 16V
C103
1-126-965-11 ELECT
22
µ
F
20% 50V
C104
1-163-251-11 CERAMIC CHIP 100pF
5%
50V
C110
1-104-664-11 ELECT
47
µ
F
20% 16V
C112
1-163-275-11 CERAMIC CHIP 1000pF
5%
50V
C113
1-104-664-11 ELECT
47
µ
F
20% 16V
C115
1-163-263-11 CERAMIC CHIP 330pF
5%
50V
C120
1-163-251-11 CERAMIC CHIP 100pF
5%
50V
C121
1-163-113-00 CERAMIC CHIP 68pF
5%
50V
REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
When indicating parts by reference number,
please include the board name.
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
