Sony KP-41S5U User Manual
Page 61
– 99 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
TU101
1-693-340-11 TUNER/VIF
X1
1-767-154-21 VIBRATOR, CERAMIC (11.5MHz)
X201
1-760-628-11 VIBRATOR, CRYSTAL (18.432MHz)
X301
1-567-504-11 OSCILLATOR, CRYSTAL (4.43MHz)
X302
1-567-505-11 OSCILLATOR, CRYSTAL (3.58MHz)
X303
1-767-127-11 VIBRATOR, CERAMIC (500kHz)
X1001
1-579-965-21 VIBRATOR, CRYSTAL (20.48MHz)
*****************************************************************************
* A-1316-355-A G BOARD, COMPLETE
***************************
4-382-854-11 SCREW (M3X10), P, SW (+)
C6001
1-119-894-51 CERAMIC
2200pF
20% 250V
C6002
!
1-104-706-51 FILM
0.22
µ
F
20%
250V
C6003
1-126-943-11 ELECT
2200
µ
F
20% 25V
C6004
1-104-665-11 ELECT
100
µ
F
20% 25V
C6006
!
1-104-706-51 FILM
0.22
µ
F
20%
250V
C6007
1-119-894-51 CERAMIC
2200pF
20% 250V
C6011
1-107-676-91 ELECT
2.2
µ
F
20% 450V
C6012
1-102-112-00 CERAMIC
330pF
10% 50V
C6018
1-117-753-11 ELECT(BLOCK) 470
µ
F
20% 450V
C6019
1-104-664-11 ELECT
47
µ
F
20% 25V
C6020
1-104-665-11 ELECT
100
µ
F
20% 25V
C6021
1-126-961-11 ELECT
2.2
µ
F
20% 50V
C6026
1-104-665-11 ELECT
100
µ
F
20% 25V
C6030
1-115-405-11 FILM
0.039
µ
F
3%
1KV
C6031
1-126-964-11 ELECT
10
µ
F
20% 50V
C6032
1-126-964-11 ELECT
10
µ
F
20% 50V
C6033
1-136-479-11 FILM
0.001
µ
F
2%
50V
C6034
1-101-810-00 CERAMIC
100pF
5%
500V
C6035
1-101-810-00 CERAMIC
100pF
5%
500V
C6036
1-126-768-11 ELECT
2200
µ
F
20% 16V
C6037
1-126-943-11 ELECT
2200
µ
F
20% 25V
C6038
1-128-548-11 ELECT
4700
µ
F
20% 25V
C6039
1-126-972-11 ELECT
1000
µ
F
20% 50V
C6040
1-126-972-11 ELECT
1000
µ
F
20% 50V
C6041
1-126-960-11 ELECT
1
µ
F
20% 50V
C6042
1-104-665-11 ELECT
100
µ
F
20% 25V
C6044
1-107-641-11 ELECT
220
µ
F
20% 160V
C6045
1-104-665-11 ELECT
100
µ
F
20% 25V
C6046
1-104-665-11 ELECT
100
µ
F
20% 25V
C6047
1-102-112-00 CERAMIC
330pF
10% 50V
C6048
1-126-960-11 ELECT
1
µ
F
20% 50V
C6049
1-136-165-00 FILM
0.1
µ
F
5%
50V
C6050
1-109-954-11 ELECT
0.47
µ
F
20% 160V
C6051
1-126-935-11 ELECT
470
µ
F
20% 6.3V
C6052
1-125-969-91 CERAMIC
680pF
10% 1KV
G
AE
R331
1-216-059-00 RES,CHIP
2.7K
5%
1/10W
R332
1-216-049-00 RES,CHIP
1K
5%
1/10W
R333
1-216-067-00 RES,CHIP
5.6K
5%
1/10W
R334
1-216-041-00 RES,CHIP
470
5%
1/10W
R335
1-216-675-91 METAL CHIP
10K
0.50%1/10W
R336
1-216-109-00 RES,CHIP
330K
5%
1/10W
R337
1-216-025-00 RES,CHIP
100
5%
1/10W
R338
1-216-049-00 RES,CHIP
1K
5%
1/10W
R339
1-216-049-00 RES,CHIP
1K
5%
1/10W
R340
1-216-025-00 RES,CHIP
100
5%
1/10W
R341
1-216-025-00 RES,CHIP
100
5%
1/10W
R342
1-216-049-00 RES,CHIP
1K
5%
1/10W
R343
1-216-061-00 RES,CHIP
3.3K
5%
1/10W
R344
1-216-067-00 RES,CHIP
5.6K
5%
1/10W
R345
1-216-025-00 RES,CHIP
100
5%
1/10W
R347
1-216-025-00 RES,CHIP
100
5%
1/10W
R348
1-216-025-00 RES,CHIP
100
5%
1/10W
R349
1-216-025-00 RES,CHIP
100
5%
1/10W
R350
1-216-041-00 RES,CHIP
470
5%
1/10W
R351
1-216-053-00 RES,CHIP
1.5K
5%
1/10W
R352
1-216-077-91 RES,CHIP
15K
5%
1/10W
R353
1-216-033-00 RES,CHIP
220
5%
1/10W
R354
1-216-295-00 SHORT
0
R355
1-216-093-91 RES,CHIP
68K
5%
1/10W
R356
1-216-133-00 RES,CHIP
3.3M
5%
1/10W
R357
1-216-049-00 RES,CHIP
1K
5%
1/10W
R358
1-216-105-00 RES,CHIP
220K
5%
1/10W
R359
1-216-295-00 SHORT
0
R360
1-216-129-00 RES,CHIP
2.2M
5%
1/10W
R361
1-216-129-00 RES,CHIP
2.2M
5%
1/10W
R370
1-216-295-00 SHORT
0
R371
1-216-033-00 RES,CHIP
220
5%
1/10W
R373
1-216-049-00 RES,CHIP
1K
5%
1/10W
R374
1-216-041-00 RES,CHIP
470
5%
1/10W
R375
1-216-049-00 RES,CHIP
1K
5%
1/10W
R376
1-216-081-00 RES,CHIP
22K
5%
1/10W
R377
1-216-049-00 RES,CHIP
1K
5%
1/10W
R378
1-216-680-00 METAL CHIP
16K
0.50%1/10W
R379
1-216-041-00 RES,CHIP
470
5%
1/10W
R1001
1-216-025-00 RES,CHIP
100
5%
1/10W
R1002
1-216-025-00 RES,CHIP
100
5%
1/10W
R1010
1-216-295-00 SHORT
0
R1012
1-216-041-00 RES,CHIP
470
5%
1/10W
R1014
1-216-065-00 RES,CHIP
4.7K
5%
1/10W
R1017
1-216-295-00 SHORT
0
R1020
1-216-097-00 RES,CHIP
100K
5%
1/10W
R1021
1-216-029-00 RES,CHIP
150
5%
1/10W
R1022
1-216-029-00 RES,CHIP
150
5%
1/10W
R1023
1-216-029-00 RES,CHIP
150
5%
1/10W
R1024
1-216-045-00 RES,CHIP
680
5%
1/10W
R1026
1-216-025-00 RES,CHIP
100
5%
1/10W
R1027
1-216-025-00 RES,CHIP
100
5%
1/10W
R1028
1-216-025-00 RES,CHIP
100
5%
1/10W
