– 96 –

The componants identified by
shading and mark

are criti-

cal for safety.
Replace only with part number
specified.

KP-41S5/41S5B/41S5G/

41S5K/41S5R/41S5U

RM-862

REF.NO.

PART NO.

DESCRIPTION

REMARK

REF.NO.

PART NO.

DESCRIPTION

REMARK

JR201

1-216-295-00 SHORT

0

JR203

1-216-295-00 SHORT

0

JR208

1-216-295-00 SHORT

0

JR209

1-216-295-00 SHORT

0

JR211

1-216-295-00 SHORT

0

JR212

1-216-295-00 SHORT

0

JR303

1-216-296-00 SHORT

0

JR304

1-216-296-00 SHORT

0

JR305

1-216-296-00 SHORT

0

JR360

1-216-295-00 SHORT

0

JR362

1-216-295-00 SHORT

0

JR1010

1-216-295-00 SHORT

0

L10

1-410-379-31 INDUCTOR CHIP

6.8

µ

H

L102

1-408-600-31 INDUCTOR

5.6

µ

H

L111

1-216-295-00 SHORT

0

L120

1-408-602-31 INDUCTOR

8.2

µ

H

L121

1-408-591-11 INDUCTOR

1

µ

H

L122

1-408-602-31 INDUCTOR

8.2

µ

H

L300

1-412-006-31 INDUCTOR CHIP

10

µ

H

L301

1-410-993-11 INDUCTOR CHIP

1

µ

H

Q1

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q4

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q15

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q17

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q18

8-729-027-38 TRANSISTOR DTA144EKA-T146

Q20

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q21

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q22

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q23

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q24

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q25

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q101

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q102

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q103

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q104

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q105

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q106

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q107

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q108

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q109

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q110

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q111

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q112

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q113

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q114

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q115

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q116

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q120

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q121

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q122

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q124

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q125

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q130

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q201

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q202

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q203

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q204

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q211

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q212

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q213

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q214

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q215

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q216

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q217

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q300

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q301

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q302

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q303

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q304

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q305

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q306

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q307

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q308

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q309

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q330

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

Q331

8-729-120-28 TRANSISTOR 2SC1623-L5L6

Q1001

1-801-806-11 TRANSISTOR DTC144EKA-T146

Q1002

8-729-026-49 TRANSISTOR 2SA1037AK-T146-R

R1

1-216-049-00 RES,CHIP

1K

5%

1/10W

R2

1-216-025-00 RES,CHIP

100

5%

1/10W

R3

1-216-025-00 RES,CHIP

100

5%

1/10W

R4

1-216-013-00 RES,CHIP

33

5%

1/10W

R5

1-216-073-00 RES,CHIP

10K

5%

1/10W

R6

1-216-667-11 METAL CHIP

4.7K

0.50%1/10W

R7

1-216-041-00 RES,CHIP

470

5%

1/10W

R9

1-216-041-00 RES,CHIP

470

5%

1/10W

R18

1-216-025-00 RES,CHIP

100

5%

1/10W

R19

1-216-025-00 RES,CHIP

100

5%

1/10W

R20

1-216-025-00 RES,CHIP

100

5%

1/10W

R21

1-216-025-00 RES,CHIP

100

5%

1/10W

R24

1-216-065-00 RES,CHIP

4.7K

5%

1/10W

R25

1-216-065-00 RES,CHIP

4.7K

5%

1/10W

R28

1-216-073-00 RES,CHIP

10K

5%

1/10W

R29

1-216-065-00 RES,CHIP

4.7K

5%

1/10W

R30

1-216-065-00 RES,CHIP

4.7K

5%

1/10W

R31

1-216-065-00 RES,CHIP

4.7K

5%

1/10W

R32

1-216-025-00 RES,CHIP

100

5%

1/10W

R33

1-216-025-00 RES,CHIP

100

5%

1/10W

R34

1-216-025-00 RES,CHIP

100

5%

1/10W

R35

1-216-025-00 RES,CHIP

100

5%

1/10W

R40

1-216-067-00 RES,CHIP

5.6K

5%

1/10W

R42

1-216-069-00 RES,CHIP

6.8K

5%

1/10W

R44

1-216-069-00 RES,CHIP

6.8K

5%

1/10W

R46

1-216-095-00 RES,CHIP

82K

5%

1/10W
