– 105 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
Q1602
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1603
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1604
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1605
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1607
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1608
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1609
1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1610
8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q1611
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1612
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1613
8-729-027-56 TRANSISTOR DTC143TKA-T146
Q1614
8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q1615
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1616
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1617
8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q1701
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1702
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1703
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1704
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1705
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1706
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1707
1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1708
8-729-027-38 TRANSISTOR DTA144EKA-T146
Q1709
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1710
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1711
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1801
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1802
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1803
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1804
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1805
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1806
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1807
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1808
8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q1809
8-729-120-28 TRANSISTOR 2SC1623-L5L6
R1501
1-216-353-00 METAL OXIDE 2.2
5%
1W
F
R1502
1-216-671-11 METAL CHIP
6.8K
0.50%1/10W
R1504
1-216-675-91 METAL CHIP
10K
0.50%1/10W
R1505
1-249-377-11 CARBON
0.47
5%
1/4W F
R1506
1-215-888-00 METAL OXIDE 220
5%
2W
F
R1507
1-216-081-00 RES,CHIP
22K
5%
1/10W
R1508
1-249-383-11 CARBON
1.5
5%
1/4W F
R1509
1-216-671-11 METAL CHIP
6.8K
0.50%1/10W
R1510
1-216-675-91 METAL CHIP
10K
0.50%1/10W
R1511
1-216-057-00 RES,CHIP
2.2K
5%
1/10W
R1512
1-216-085-00 RES,CHIP
33K
5%
1/10W
R1513
1-216-049-00 RES,CHIP
1K
5%
1/10W
R1514
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1515
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1516
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1517
1-216-081-00 RES,CHIP
22K
5%
1/10W
R1518
1-216-353-00 METAL OXIDE 2.2
5%
1W
F
R1519
1-216-073-00 RES,CHIP
10K
5%
1/10W
R1520
1-216-089-00 RES,CHIP
47K
5%
1/10W
D
D1804
8-719-923-60 DIODE MTZJ-T-77-9.1A
D1805
8-719-923-60 DIODE MTZJ-T-77-9.1A
D1806
8-719-923-60 DIODE MTZJ-T-77-9.1A
IC1501
8-759-192-71 IC STV9379
IC1502
8-759-251-31 IC CA0007AM
IC1503
8-759-998-98 IC LM358D
IC1602
8-759-250-68 IC TDA7264
IC1603
8-759-502-21 IC TDA2822M
IC1701
8-752-908-27 IC CXP86213-003S
IC1702
8-759-527-76 IC M24C08-MN6T
IC1703
8-759-100-96 IC
µ
PC4558G2
IC1704
8-759-100-96 IC
µ
PC4558G2
IC1706
8-759-352-91 IC PST9143NL
IC1801
8-759-144-82 IC
µ
PC2405HF
IC1802
8-759-095-63 IC PQ09RF2
IC1803
8-759-231-58 IC TA7812S
IC1804
8-759-069-28 IC PQ05RF11
IC1805
8-759-100-96 IC
µ
PC4558G2
J1601
1-784-653-11 JACK, PHONO 2P
JR1502
1-216-295-91 SHORT
0
JR1503
1-216-295-91 SHORT
0
JR1504
1-216-295-91 SHORT
0
JR1505
1-216-295-91 SHORT
0
JR1506
1-216-295-91 SHORT
0
JR1508
1-216-295-91 SHORT
0
JR1510
1-216-295-91 SHORT
0
JR1511
1-216-295-91 SHORT
0
JR1512
1-216-295-91 SHORT
0
JR1513
1-216-295-91 SHORT
0
JR1514
1-216-295-91 SHORT
0
JR1701
1-216-295-91 SHORT
0
L1501
1-412-524-11 INDUCTOR
8.2
µ
H
L1601
1-402-711-11 INDUCTOR
0
µ
H
L1602
1-402-711-11 INDUCTOR
0
µ
H
L1701
1-408-603-31 INDUCTOR
10
µ
H
L1702
1-408-598-31 INDUCTOR
3.9
µ
H
L1801
1-408-603-31 INDUCTOR
10
µ
H
Q1501
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1502
8-729-920-72 TRANSISTOR 2SA1037K-T-146-QR
Q1503
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1505
8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1601
8-729-027-56 TRANSISTOR DTC143TKA-T146
