Version 1.1
- 26 -
◆ Camera Control Command
Command Byte4 Byte5 Byte6 Byte7 Byte8 Items Ack
COMMUNICA
TION
PROTOCOL 02H 19H 03H 00H **H
00H: SAMSUNG 01H: VICON
02H: PANASONIC 03H: PHILIPS
04H: PELCO-P 05H: KALATEL
06H: ERNA 07H: DIAMOND
08H: VCLTP 09H: PELCO-D
O
BAUDRATE 02H 19H 00H 00H **H
00H: 4800 bps, 01H: 9600 bps
02H: 19200 bps, 03H: 38400 bps
O
ADDRESS 02H 19H 01H 00H **H 00H~FFH: 0~255 O
* When you change the protocol, maybe the baudrate and the address will be changed automatically
because some protocol is not support some baudrate and address.
KEY(SWITCH)
ENTER 03H 18H FFH 00H FFH O
UP 03H 03H FFH 00H FFH O
DOWN 03H 09H FFH 00H FFH O
LEFT 03H 05H FFH 00H FFH O
RIGHT 03H 07H FFH 00H FFH O
SYSTEM
RESET 02H 00H 00H 00H 00H Camera reboot O
FACTORY DEFAULT 02H 01H 00H 00H 00H Return to factory default setting O
REQUEST MODEL
NAME
FCH 00H 00H 00H FCH A0 FD 00 FC 00 00 00 FC 0A O
INFORMATION
DISPLAY
02H 1CH 00H 00H **H 00H: OFF, 01H: ON O
COMMAND
OPERATION SAVE 02H 22H 00H 00H 00H O
OPERATION CANCEL 02H 23H 00H 00H 00H O
OSD
(MAIN MENU)
ON 03H 17H 01H 00H FFH O
OFF 03H 17H 00H 00H FFH O
OSD COLOR 02H 1BH 00H 00H **H 00H: BW, 01H: R, 02H: G, 03H: B O
CAMERA
ID
CAMERA ID
OPERATION
02H 0AH 00H 00H **H 00H: OFF, 01H: ON O
ID SET 02H 0AH 01H *1H *2H
*1H (CAMERA ID Sequence)
01H~36H: 0 ~ 54
*2H (String) : note the below table
O
*String Table
00H A 05H F 0AH K 0FH P 14H U 19H Z 1EH 4 23H 9 28H +
01H B 06H G 0BH L 10H Q 15H V 1AH 0 1FH 5 24H space 29H *
02H C 07H H 0CH M 11H R 16H W 1BH 1 20H 6 25H : 2AH (
03H D 08H I 0DH N 12H S 17H X 1CH 2 21H 7 26H ? 2BH )
04H E 09H J 0EH O 13H T 18H Y 1DH 3 22H 8 27H - 2CH /
ID LOCATION 02H 0AH 02H 00H **H
00H: UP 01H: DOWN
02H: LEFT 03H: RIGHT
O
IRIS
ALC (Auto Iris) 02H 02H 00H 00H 00H Iris Auto O
ALC LEVEL 02H 02H 00H 02H **H 00H~40H: -32~+32 O
BLC OFF 02H 02H 03H 00H 00H Back Light Compensation Off O
BLC ON 02H 02H 03H 00H 01H Back Light Compensation On O
BLC ON
AREA set
02H 02H 04H 00H **H
00H: USER 01H: BOTTOM
02H: TOP 03H: LEFT
04H: RIGHT 05H: CENTER
O
BLC ON
AREA DISPLAY ON
02H 02H 06H 00H **H 00H: OFF 01H: ON O
BLC ON USER
SIZE & LOCATION
02H 02H 04H *1H *2H
*1H
01H: SIZE change
02H: LOCATION change
*2H
00H: height increase / move up
01H: height decrease / move down
02H: width decrease / move left
03H: width increase / move right
O
